Driving Strength Profile
Options are: Auto (default), 667MHz, 800MHz, 1066MHz, OC-1200, OC-1333.
Data Driving Pull-Up Level
Options are: Auto (default), +8~-7.
Cmd Driving Pull-Up Level
Options are: Auto (default), +8~-7.
Ctrl Driving Pull-Up Level
Options are: Auto (default), +8~-7.
Clk Driving Pull-Up Level
Options are: Auto (default), +8~-7.
Data Driving Pull-Down Level
Options are: Auto (default), +8~-7.
Cmd Driving Pull-Down Level
Options are: Auto (default), +8~-7.
Ctrl Driving Pull-Down Level
Options are: Auto (default), +8~-7.
Clk Driving Pull-Down Level
Options are: Auto (default), +8~-7.
DDR Write Training
Allows you to determine whether to fine-tune memory parameters to enhance memory compatibility.
Auto
Lets the BIOS decide whether to enable this function. (Default)
Disabled Disables this function.
Enabled Enables this function to enhance memory compatibility.
Channel A/B Driving Settings
CMOS Setup Utility-Copyright (C) 1984-2008 Award Software
Channel A Driving Settings
: Move
Enter: Select
+/-/PU/PD: Value
F10: Save
ESC: Exit
F1: General Help
F5: Previous Values
F6: Fail-Safe Defaults
F7: Optimized Defaults
x
Driving Strength Profile
Auto
x
Data Driving Pull-Up Level
Auto
x
Cmd Driving Pull-Up Level
Auto
x
Ctrl Driving Pull-Up Level
Auto
x
Clk Driving Pull-Up Level
Auto
x
Data Driving Pull-Down Level
Auto
x
Cmd Driving Pull-Down Level
Auto
x
Ctrl Driving Pull-Down Level
Auto
x
Clk Driving Pull-Down Level
Auto
Item Help
Menu Level
