4 www.goodmanmfg.com SS-CPG180-240
P
roduct
S
PecificationS
p
rodUCT
s
peCiFiCaTions
— 20 T
ons
CPG240
4003B***B*
CPG240
4004B***B*
CPG240
4007B***B*
Cooling Capacity
Total, BTU/h
240,000 240,000 240,000
Sensible BTU/h 170,000 170,000 170,000
EER / IEER 9.8 / 10.0 9.8 / 10.0 9.8 / 10.0
Decibels 88.3 88.3 88.3
AHRI Reference #s 5327364 5327364 5327364
Heating Capacity
High Input / Output (KBTU/h)
400 / 320 400 / 320 400 / 320
Low Input / Output (KBTU/h) 300 / 240 300 / 240 300 / 240
Steady State Efficiency (%) 80 80 80
Temperature Rise Range (°F) High/Low 25-55 / 15-45 25-55 / 15-45 25-55 / 15-45
No. of Burners 8 8 8
Evaporator Motor / Coil
Motor Type (Belt Drive)
Std Static Belt Drive Std Static Belt Drive Std Static Belt Drive
Indoor Nominal CFM 7,000 7,000 7,000
Indoor Motor FLA (Cooling) 12.7 6.4 5.1
Horsepower - RPM 5.0 - 1,725 5.0 - 1,725 5.0 - 1,725
Metering Device TXV TXV TXV
Filter Size (#) 20 x 25 x 2 (6) 20 x 25 x 2 (6) 20 x 25 x 2 (6)
Drain Size (NPT) 1" 1" 1"
R-410A Refrigerant Charge Cir #s 1 & 2 200 ozs. 200 ozs. 200 ozs.
Evaporator Coil Face Area (ft²) 20 20 20
Rows Deep / Fins per Inch 4 / 16 4 / 16 4 / 16
Belt Drive Evap Fan Data
# of Wheels (D x W)
2 (15" x 15") 2 (15" x 15") 2 (15" x 15")
Motor Sheave 1VP60 x 1⅛" 1VP60 x 1⅛" 1VP60 x 1⅛"
Blower Sheave / Belt BK100 x ⁷/₁₆" / BX46 BK100 x ⁷/₁₆" / BX46 BK100 x ⁷/₁₆" / BX46
Condenser Fan / Coil
Quantity of Condenser Fan Motors
3 3 3
Horsepower - RPM ⅓ - 1,075 ⅓ - 1,075 ⅓ - 1,075
Fan Diameter / # Fan Blades 22 / 3 22 / 3 22 / 3
Outdoor Nominal CFM 7,200 7,200 7,200
Face Area (ft²) 53.3 53.3 53.3
Rows Deep / Fins per Inch 2 / 27 2 / 27 2 / 27
Compressor
Quantity / Type
2 / Scroll 2 / Scroll 2 / Scroll
Compressor RLA / LRA ea. 33.3 / 239 17.9 / 125 12.8 / 80
Electrical Data / Static
Voltage / Phase / Frequency
208-230/3/60 460/3/60 575/3/60
Standard Max Static 1.4 1.4 1.4
Outdoor Fan FLA / LRA 2.4 / 5.2 1.2 / 2.6 .9 / 2.2
Total Unit Amps 86.5 45.8 33.4
Min. Circuit Ampacity¹ 95 50 37
Max. Overcurrent Protection (amps)² 125 60 45
Entrance Power Supply 2⅛" 2⅛" 2⅛"
Entrance Control Voltage ⅞" ⅞" ⅞"
Operating / Shipping Weight (lbs) 2242/ 2357 2242/ 2357 2242/ 2357
¹ Wire size should be determined in accordance with National Electrical Codes. Extensive wire runs will require larger wire sizes.
² May use fuses or HACR-type circuit breakers of the same size as noted.
Notes
• Always check the S&R plate for electrical data on the unit being installed.
• When a factory installed convenience outlet is installed in the equipment the unit MCA will increase by 7.5A for 208/230V units,
increase by 3.75A for 460V units and by 3A for 575V units. The MOP device must be sized accordingly.
