Standard Belt Drive ― Down Shot
ESP
In" H₂O
Turns Open
0
1
2
3
4
5
6
CFM
BHP
CFM
BHP
CFM
BHP
CFM
BHP
CFM
BHP
CFM
BHP
CFM
BHP
0.2
---
---
---
---
9,359
4.9235
8,991
3.7928
8,621
3.5442
8,188
3.2694
7,826
3.0421
0.4
---
---
9,018
3.1834
8,632
4.3858
8,251
3.3897
7,867
3.1452
7,363
2.8481
6,992
2.6282
0.6
---
---
8,279
2.9618
7,879
3.8623
7,484
2.9949
7,085
2.7548
---
---
---
---
0.8
7,957
4.8180
7,513
2.7320
7,097
3.3548
---
---
---
---
---
---
---
---
1.0
7,179
4.2309
6,716
2.4930
---
---
---
---
---
---
---
---
---
---
1.2
6,368
3.6582
---
---
---
---
---
---
---
---
---
---
---
---
High-Static Belt Drive ― Down Shot
ESP
In" H₂O
Turns Open
0
1
2
3
4
5
6
CFM
BHP
CFM
BHP
CFM
BHP
CFM
BHP
CFM
BHP
CFM
BHP
CFM
BHP
1.0
---
---
---
---
---
---
9,001
6.8290
8,394
6.0087
7,797
4.7808
7,227
4.2762
1.2
---
---
---
---
8,891
6.8284
8,262
6.1503
7,632
5.3530
7,012
4.1965
---
---
1.4
---
---
8,811
6.8641
8,148
6.1510
7,495
5.4811
6,841
4.7084
---
---
---
---
1.6
---
---
8,065
6.1877
7,377
5.4834
---
---
---
---
---
---
---
---
1.8
7,998
6.8862
7,290
5.5213
---
---
---
---
---
---
---
---
---
---
2.0
7,221
6.1024
---
---
---
---
---
---
---
---
---
---
---
---
Notes
• Airflow table represent dry coil with filters installed; SCFM correction factor for wet coil is 4%.
• Any adjustment made to the blower should not cause the motor to draw more than the motor rated RLA. Applica-
tion that exceed the above could require a larger motor. Minimum rated SCFM is 350 per ton.
• High-static airflow requires installation of high kit (HSKT240) or factory-built high-static model.
• Unit factory shipped with the sheave set at 2.5 turns open.
