Adjustable Base:
14. Make sure the safety seat/base is not tilted sideways on the vehicle
seat. Check the level indicator. You must look straight on at the indicator.
!
If the indicator shows ONLY blue, the safety seat is properly leveled.
!
If any orange is showing in the level indicator, the safety seat is either
too upright or too reclined. To correct the problem, first note the degree
of correction needed, then follow the instructions below:
Loosen the base by releasing the seat
belt to access the recline adjustment knob.
If the safety seat is too upright, turn
the knob clockwise to increase the
recline Ê . If you still need more recline
after the adjustment foot is completely
extended, place rolled towels under foot
until indicator shows ONLY blue.
If the safety seat is too reclined, retract
the adjustment foot into the base by
turning the knob counterclockwise or
shift safety seat manually to decrease
the recline.
Use adjustment knob
to change recline
К
50
