Graco 13785-7-00 - Manual (Page 30)

26
Vehicle
belt path
Non-adjustable Base
The level indicator is attached to the side of
the safety seat, and indicates whether or not the
safety seat is properly reclined.
The locking clip is stored on the back of
the safety seat. You will need to use it with
certain types of vehicle seat belts.
The recline adjustment knob raises and lowers
the foot beneath the base which helps to properly
recline the safety seat/base.
Adjustable Base
Recline
adjustment
foot
Recline
adjustment
knob
Vehicle
belt path
Locking
Clip
Level
Indicator
Recline
Adjustment
Knob
(certain models)
