For the 5-Point Harness:
1. Lift the seat flap to access the harness
adjuster button. Depress the harness adjuster
button and loosen the harness Ê .
2. Behind the seat, pull the small strap down
until the metal junction plate is below the
plastic harness retainer. Remove the ends of
the two shoulder straps from the metal junction
plate Ë . From the front of the seat, pull the
straps through the shoulder slots and seat
pad. Insert the straps all the way through the
appropriate shoulder slots as determined in
step 2 on page 31.
Л
К
34
