27 308876
Technical Data
Category Data
Maximum Fluid Pressure 4000 psi (28 MPa, 276 bar)
Maximum Cylinder Air Pressure 120 psi (0.84 MPa, 8.4 bar)
Air inlets (open and close ports) 1/8 npt(f)
Fluid Inlet 1/4 npt(f)
Fluid Outlet 1/4 npt(f) and 3/4–16 unf(m)
Fluid Viscosity Range 20 cps to 1 million cps
Snuffer Action Fluid Section Isolation chamber with zerk fittings
Divorced Air Cylinder Piston cylinder, EP o-rings
Weight
Aluminum Valve
Stainless Steel Valve
Handle Kit 1.43 lb (0.65 kg)
2.07 lb (0.94 kg)
0.77 lb (0.35 kg)
Wetted Parts
Aluminum Valve aluminum, 303 stainless steel, 17–4 PH stainless steel, C2 car-
bide, hard chrome, ethylene propylene, Parker Polymite
t
, PTFE
Stainless Steel Valve 303 stainless steel, 17–4 PH stainless steel, C2 carbide, hard
chrome, ethylene propylene, Parker Polymite
t
, PTFE
Severe-duty Components
Shaft
Snuffer Needle
Seat
Shaft Seal, standard
Shaft Seal, optional Hard chrome over 303 stainless steel
Hardened 440–C stainless steel
Reversible, solid C2 carbide inserts
High density Parker Polymite
t
PTFE
Loctite r is a registered trademark of the Loctite Corporation.
