About the Boards
About the 3-Stack Platform System
5
i.MX31 PDK 1.4 Quick Start Guide
Debug Port
• RealView
®
-ICE debug support
Video and Audio
Stereo
• Stereo microphone jack, headphone and video jack,
stereo and mono (ear piece) speaker terminals
GPS Connector
• One connector to outboard GPS module
FM Receiver
TV Out
• TV decoder that supports 8-bit color, NTSC and PAL
formats
PC Card Expansion
• SD card connectors, with card sense
Keypad
• Onboard keypad and keypad connector
Network Support
• Onboard Wi-Fi CERTIFIEDFter IEEE 802.11 b/g
standards and Bluetooth(r) Core Specification
Version 2.0 + EDR (enhanced data rate)
combination module
• One Ethernet jack connector (for application/debug)
USB
• One USB OTG high-speed transceiver with mini-
USB connector
• One USB high-speed host transceiver, with
standard USB host connector
ATA Support
ATA5 controller with
• One 44-position dual row 2 mm header for small
form-factor disk drivers
• One 40-pin ZIF connector for Toshiba HDD
Accelerometer
• Onboard accelerometer with sensitivity in three
separate axes (X, Y, Z)
Serial Port
Two RS-232 interfaces with DB-9 connectors
• One RS-232 interface is driven by a UART channel
internal to the MX31, and it supports DCE with
optional full modem controls
• The other RS-232 interface is DTE with optional full
modem controls
Table 1.1 3-Stack Platform Features
