Page 26
—26—
7. REPLACEMENT PARTS LIST
• MODEL: ZQ08A10C
A
FRONT GRILLE ASSY
3531A20034C
1
R
1
673-044-02
FRONT GRILLE
3530A10026A
1
R
2
673-061-01
INLET GRILLE
3530A10028A
1
R
3
AIR FILTER ASSY
5231A20004A
1
R
4
LOUVER, HORIZONTAL
4758A20002A
1
R
5
673-062-50
VERTICAL LOUVER
4758A30008A
2
R
6
CABINET ASSY
3091A30005C
1
R
B
COMP & ACCESSORY ASSY
7
673-019-00
ANTI-VIBRATION BUSH
5040AR4195A
3
R
8
COMPRESSOR
5416A20014B
1
R
9
BRACKET, WASHER
4810AR4155A
3
N
10
673-017-00
HEXAGON NUTS
1NHA0801206
3
N
11
673-015-02
GASKET
4986A30001A
1
R
12
OVERLOAD PROTECTOR
6750A30001N
1
R
13
673-013-02
SPRING
4970A30009A
1
R
14
673-012-02
TERMINAL COVER
3550A30048A
1
R
15
673-011-00
GASKET-NUT
4H01058A
1
R
16
673-010-00
NUT, TERMINAL COVER
4H00947A
1
R
17
BASE PAN WELD ASSY
3041A30011D
1
R
18
673-068-00
BARRIER, SINGLE
4790A10008A
1
R
19
SCROLL
3072A20004A
1
R
20
AIR GUIDE
5238A10006A
1
R
21
673-035-02
VENTILATION DAMPER
4901A30001A
1
R
22
MOTOR MOUNT
4960A20014A
1
R
23
MOTOR ASSY
4681A20073A
1
R
24
673-069-01
SCREW
4000W4A003A
2
N
25
673-069-00
SCREW, TAP
4H00006D
4
N
26
SHROUD
4998A10019A
1
R
27
TURBO
5900A10008A
1
R
28
FAN
5900A20015A
1
R
29
673-025-00
CLAMP SPRING
3H02932B
2
R
30
ORIFICE
4948A30007A
1
R
31
673-039-01
BRACE
4800A30001A
1
R
32
EVAPORATOR ASSY
5421A20061E
1
R
33
CONDENSER ASSY
5403A20092A
1
R
34
673-071-00
RUBBER
4H02023A
1
R
PART NO.
DESCRIPTION
REMARK
ZQ08A10C
LOCATION
NO
.
FRIEDRICH
PART NO.
Q'TY
PER SET
