PRIMEPOWER Options

Data Sheets: http://www.fujitsu-siemens.com/primepower

Category

Description

Details

IME

R 1500

PRI

EPO

WER 2

IME

R 2500

IME

R 250F

IME

R 250N

PRI

EPO

WER 4

IME

R 450N

PRI

EPO

WER 6

PRI

EPO

WER 8

PRI

EPO

WER 9

PRI

EPO

WER p

PW RACK Co

ystem

Console

ode

nd User

rice (£)

mme

Options matrix
Miscellaneous (Continued)

Ext PCI box 12 slot f. PW 650/850 f.PCR2

The PCI box comes with : , 12 PCI slots, 3 slots 33/66 MHz (1 long slot), 9 slots 33
MHz (3 long slots), 2 cable carrier ZB527 for 19" rack (BG5x), you need approx. 1m
cable length in addition , for more details see rack configurator, 2 support brackets
ZB5211 for PRIMECENTER 19 rack Rack space required and max. number of boxes
max. 1 box may be connected to a PW650, max. 2 boxes may be connected to a
PW850, requires 4U in a 19rack, direct above the server

D:GP70M-BG61

6434

PCI/DISK box 10PCI slot 4HDD bay f PW900

The PCI/DISK box comes with : , 2x Ethernet ports, 10/100Mbit/s, 2x console ports
RS232C , 10 PCI slots, 7 slots 33 MHz (5 short, 2 long), 3 slots 33/66 MHz (1 short, 2
long), 2 SCSI ports and 4 HDD bays for system volume, 2 bays are connected to each
(of the 2) SCSI ports (40Mbyte/s) this connection is fix and cannot be changed, cable
carrier and support brackets for mounting into 19" rack PRIMECENTER2 (GB5x).,
Rack space required, max. 1 box may be connected to each system board, BG61
requires 4U in a 19 rack, directly above the server., As an exception you may mount
Rack console with TFT monitor + keyboard (from the SMC) between Server and
PCI/DISK box.

D:GPK09-BG61

34266

Ext I/O box 10pci slot 4HDD bay PW 1500

The PCI/DISK box comes with : , 2x Ethernet ports, 10/100Mbit/s, 2x console ports
RS232C , 10 PCI slots, 7 slots 33 MHz (5 short, 2 long), 3 slots 33/66 MHz (1 short, 2
long), 2 SCSI ports and 4 HDD bays for system volume, 2 bays are connected to each
(of the 2) SCSI ports (40Mbyte/s) , this connection is fix and cannot be changed, Rack
space required, max. 1 box may be connected to each system board, BG62 requires
4U in a 19rack, either in the PW1500 system cabinet or in an optional I/O cabinet
(GPK15-BG70)

D:GPK15-BG62

34266

PCI/DISK box 10PCI slot 4HDD bay PW2500

The PCI/DISK box comes with : ·, 2x Ethernet ports, 10/100Mbit/s·, 2x console ports
RS232C, used in XPAR configurations only·, 10 PCI slots·, 7 slots 33 MHz (5 short, 2
long)·, 3 slots 33/66 MHz (1 short, 2 long)·, 2 SCSI ports and 4 HDD bays for system
volume·, 2 bays are connected to each (of the 2) SCSI ports (40Mbyte/s) ·, this
connection is fix and cannot be changed·, Boot-PROM, used in XPAR configurations
only·, Cables for connecting to the SB and mounting kit for installing into a I/O
cabinetRack space required·, max. 2 boxes may be connected to each systemboard·,
BG63 requires 4U in an I/O cabinet GPK25-BG71.

D:GPK25-BG63

17483

Keyboard /Mouse

Mouse, PS2, optical, with Scroll Wheel

Optical technology, Techniques from Logitech Cooperation, Precise and comfortable
navigation due to LED sensor with 400 dpi resolution, Country-specific warranty,
Ergonomics:, Two Button Mouse, Wheel works also as third Button, Optimized for
right and left hand use

x D:TMA-3T

Orig. SUN USB Keyb. + Mouse, Internat.

Keyboard with USB-connector,International, incl. USB-3-keys mouse, only table
device.

x D:GPRAC-TAS24

Keyboard, PS2, international

with cable 1,4m with plug PS2 type

x D:TAMFL-E811

Cables

Cable & Adapter to Modem(3m)

Modem Cable (3m) + Adapter for connection to PW-based SMC or LAN Console,
PW250 and PW450, , Adapter: 25pins D-Sub male <-> RJ45 jack , Cable : RJ45 plug
<-> RJ45 plug

x D:GP70P-KA04

Cable & Adapter to Modem(10m)

Modem Cable (10m) + Adapter for connection to PW-based SMC or LAN Console,
PW250, and PW450, , Adapter: 25pins D-Sub male <-> RJ45 jack , Cable : RJ45 plug
<-> RJ45 plug

x D:GP70P-KA05

Cable & Adapter f. ISDN TA (3m)

ISDN TA Cable for MD02 (3m) + Adapter for connection to PW-based SMC or LAN
Console, PW250 and PW450, , Adapter: 9pin D-Sub male <-> RJ45 jack, Cable :
RJ45 plug <-> RJ45 plug

x D:GP70P-KA06

Cable & Adapter f. ISDN TA (10m)

ISDN TA Cable for MD02 (10m) + Adapter for connection to PW-based SMC or LAN
Console, PW250 and PW450, , Adapter: 9pin D-Sub male <-> RJ45 jack, Cable :
RJ45 plug <-> RJ45 plug

x D:GP70P-KA07

RC23 cable kit USB

USB cable for console connection, , USB_B <-->USB, cable length: 3m. IT is needed
only for the console wiring with the keyboard drawer in connection with a monitor on
the baseplate for 17/19inch displays.

D:GP70P-KA51

Signal-Cable Power-Control Connection

Power control connection cable for PW server power on.

D:GP7KB-1903

Power cord IEC320 device 2.5m (F/M)

power cable, cold-cold

D:KB258-C250

Adaptercable D-SUB9 to RJ45

Connection UPS to PW250x / PW450x, D-SUB9 to COM RJ45

D:UPS-V24-RJ45KAB

Power Cable, UK, 3m

x D:KB8GB-M3

VGA-Extension Cable 1.8m

VGA extension cable for the connection between the monitor and server., With
connection of console about Switch NO VGA extension is necessary., BY
CONNECTION FROM CONSOLE WITHOUT SWITCH A VAG-EXTENSION
ALWAYS IS NEEDED.

x D:GPRAC-KB01

PS2-cable extension, 1,8m

PS2-cable extension, 1.8m:, 1 cable for keyboard connect and 1 cable for mouse
connect, WITH CONNECTION OF CONSOLE OVER SWITCH, NO PS2-EXTENSION
IS NECESSARY!, WITH WIRING OF CONSOLE WITHOUT SWITCH ALWAYS
BECOMES A PS2-EXTENSION REQUIRED

x D:GPRAC-KB02

Modem Cable D-Sub 25p(f)-25p(m), Pin 1:1

Modem Cable - serial line to the server interface, Length 5m, D-Sub 25pol.(f) - D-Sub
25pol.(m); pin assignment 1:1

x D:GPRAC-KB03

Adapter for PS/2<->USB

Adapter for PS/2 <-->USB, Only for connecting PW-Server with Keyboard/Mouse/VGA
of the rackconsole MO04-MO09!, Not useable for conneting with the RC23 (MO04Z17-
MO09Z17)

D:GP70P-KA01

105

Adaption for PS/2-VGA on KVM-RJ45

smart cable adapter between server and CAT5 cable, incl. assembly, 2x PS/2 + 1x
VGA to RJ45 connector

D:GPRAC-AN10

143

Consol Switch KSxxxx Cable CAT 5 2_m

Cable UTP CAT5, RJ45, color blue, incl. assembly., , Note: Connection is not possible
for 4-/8- switches KS04/KS08!

D:GPRAC-KB161

Power cable (F/M) 16A 2.5m

Power cable, 16A, with F/M (C19/C20) connect for connection to UPS

D:KB259-C250

Consol Switch KSxxxx Cable CAT 5 5_m

Cable UTP CAT5, RJ45, color blue, , Attention: connection with previous 4-field/8 -
field switches KS04/KS08 is not possible!

D:GPRAC-KB162

Adaption for USB-VGA on KVM-RJ45

intelligent cable adapter between server ans CAT5 cable incl. mounting, 1x USB + 1x
VGA on RJ45-connector

x D:GPRAC-AN20

143

Adaption for USB-VGA on KVM-RJ45

intelligent cable adapter between server ans CAT5 cable incl. mounting, 1x USB + 1x
VGA on RJ45-connector

D:GPRAC-AN20

143

Adaption for SUN-I/O-VGA on KVM-RJ45

Keyboard, Mouse, Monitor- System connect on PW200/400/6x0/850 over GPRAC-
KBxxx on GPRAC-KS0801/16xx

D:GPRAC-AN30

175

Consol Switch KSxxxx Cable CAT 5 flex_m

Cable UTP CAT5, RJ45, color blue, length is customised (depends on mounting
requirements), incl. assembly.

D:GPRAC-KB16C

RCI cable RJ45 6pin(S)-RJ45 6pin(S) 4m

D:GP7KB-1204

Cable for consolconnection unit 5 m

Cable for connecting console with MCCU (PW900/1500/2500), DSub 9pins female <--
> DSub 25pins male

D:GP7KB-1805

133

RCI cable RJ45 6pin(S)-RJ45 6pin(S) 10m

D:GP7KB-1210

UTP CAT 5 Eth-cable 2xRJ45 8pin(S) 5m

UTP category 5 straight-through cable 10/100 Mbit Ethernet. For connection with a
Hub o. Switch.

D:GP7KB-1305
