PRIMERGY BX630 Data Sheets: http://www.fujitsu-siemens.com/primergy
Model Description Details Code End User Price (£) Comments
Base unit configurations
PRIMERGY BLADE BX630 Dual DP
PY BX630 Dual/OHE275 2x1M/2G Dual Server Blade equipped with 1x AMD Opteron HE processor for PRIMERGY BX600 (max. 10 server
blades), DDR 400 PC-3200 ECC, 2x GBit Ethernet LAN on-board, one I/O on-board slot can be optional
occupied with 1x Dual FC or 1x Dual LAN - I/O module, HDD controller (SATA or SAS) must be
configured as decided, 2 bays for 3.5" SATA or SAS HDD`s (hot-plug), one bay can be optional
occupied with a PCI slot module, graphics controller ATI Radeon 7000-M 16MB on-board, special
connector for Y-cable with 2x USB and 1x VGA interface. S26361-K1025-V522 1414 Phased out
PY BX630 Dual/O275 2x1M/2G Dual Server Blade equipped with 1x AMD Opteron processor for PRIMERGY BX600 (max. 10 server
blades), DDR 400 PC-3200 ECC, 2x GBit Ethernet LAN on-board, one I/O on-board slot can be optional
occupied with 1x Dual FC or 1x Dual LAN - I/O module, HDD controller (SATA or SAS) must be
configured as decided, 2 bays for 3.5" SATA or SAS HDD`s (hot-plug), one bay can be optional
occupied with a PCI slot module, graphics controller ATI Radeon 7000-M 16MB on-board, special
connector for Y-cable with 2x USB and 1x VGA interface. S26361-K1025-V168 1380 Phased out
PY BX630 Dual/O275 2x1M/4G Dual Server Blade equipped with 1x AMD Opteron processor for PRIMERGY BX600 (max. 10 server
blades), DDR 400 PC-3200 ECC, 2x GBit Ethernet LAN on-board, one I/O on-board slot can be optional
occupied with 1x Dual FC or 1x Dual LAN - I/O module, HDD controller (SATA or SAS) must be
configured as decided, 2 bays for 3.5" SATA or SAS HDD`s (hot-plug), one bay can be optional
occupied with a PCI slot module, graphics controller ATI Radeon 7000-M 16MB on-board, special
connector for Y-cable with 2x USB and 1x VGA interface. S26361-K1025-V169 1747 Phased out
PY BX630 Dual/O280 2x1M/2G Dual Server Blade equipped with 1x AMD Opteron processor for PRIMERGY BX600 (max. 10 server
blades), DDR 400 PC-3200 ECC, 2x GBit Ethernet LAN on-board, one I/O on-board slot can be optional
occupied with 1x Dual FC or 1x Dual LAN - I/O module, HDD controller (SATA or SAS) must be
configured as decided, 2 bays for 3.5" SATA or SAS HDD`s (hot-plug), one bay can be optional
occupied with a PCI slot module, graphics controller ATI Radeon 7000-M 16MB on-board, special
connector for Y-cable with 2x USB and 1x VGA interface. S26361-K1025-V182 1421 Phased out
PY BX630 Dual/O280 2x1M/4G Dual Server Blade equipped with 1x AMD Opteron processor for PRIMERGY BX600 (max. 10 server
blades), DDR 400 PC-3200 ECC, 2x GBit Ethernet LAN on-board, one I/O on-board slot can be optional
occupied with 1x Dual FC or 1x Dual LAN - I/O module, HDD controller (SATA or SAS) must be
configured as decided, 2 bays for 3.5" SATA or SAS HDD`s (hot-plug), one bay can be optional
occupied with a PCI slot module, graphics controller ATI Radeon 7000-M 16MB on-board, special
connector for Y-cable with 2x USB and 1x VGA interface. S26361-K1025-V183 1787 Phased out
PY BX630 Dual/O285 2x1M/2G Dual Server Blade equipped with 1x AMD Opteron processor for PRIMERGY BX600 (max. 10 server
blades), DDR 400 PC-3200 ECC, 2x GBit Ethernet LAN on-board, one I/O on-board slot can be optional
occupied with 1x Dual FC or 1x Dual LAN - I/O module, HDD controller (SATA or SAS) must be
configured as decided, 2 bays for 3.5" SATA or SAS HDD`s (hot-plug), one bay can be optional
occupied with a PCI slot module, graphics controller ATI Radeon 7000-M 16MB on-board, special
connector for Y-cable with 2x USB and 1x VGA interface. S26361-K1025-V185 1536 Phased out
PY BX630 Dual/O285 2x1M/4G Dual Server Blade equipped with 1x AMD Opteron processor for PRIMERGY BX600 (max. 10 server
blades), DDR 400 PC-3200 ECC, 2x GBit Ethernet LAN on-board, one I/O on-board slot can be optional
occupied with 1x Dual FC or 1x Dual LAN - I/O module, HDD controller (SATA or SAS) must be
configured as decided, 2 bays for 3.5" SATA or SAS HDD`s (hot-plug), one bay can be optional
occupied with a PCI slot module, graphics controller ATI Radeon 7000-M 16MB on-board, special
connector for Y-cable with 2x USB and 1x VGA interface. S26361-K1025-V186 1902 Phased out
PRIMERGY BLADE BX630 Dual MP
PY BX630 Dual/O875 2x1M/2G Dual Server Blade equipped with2x AMD Opteron processors (scalable to Quad) for PRIMERGY BX600
(max. 10 server blades), DDR 400 PC-3200 ECC, 2x GBit Ethernet LAN on-board, one I/O on-board slot
can be optional occupied with 1x Dual FC or 1x Dual LAN - I/O module, HDD controller (SATA or SAS)
must be configured as decided, 2 bays for 3.5" SATA or SAS HDD`s (hot-plug), one bay can be optional
occupied with a PCI slot module, graphics controller ATI Radeon 7000-M 16MB on-board, special
connector for Y-cable with 2x USB and 1x VGA interface. S26361-K1025-V258 2001 Phased out
PY BX630 Dual/O875 2x1M/4G Dual Server Blade equipped with2x AMD Opteron processors (scalable to Quad) for PRIMERGY BX600
(max. 10 server blades), DDR 400 PC-3200 ECC, 2x GBit Ethernet LAN on-board, one I/O on-board slot
can be optional occupied with 1x Dual FC or 1x Dual LAN - I/O module, HDD controller (SATA or SAS)
must be configured as decided, 2 bays for 3.5" SATA or SAS HDD`s (hot-plug), one bay can be optional
occupied with a PCI slot module, graphics controller ATI Radeon 7000-M 16MB on-board, special
connector for Y-cable with 2x USB and 1x VGA interface. S26361-K1025-V259 2367 Phased out
PRIMERGY BX630 - scalable dual socket server blade
The PRIMERGY Blade Ecosystem is a perfect choice for today’s datacenter solutions, where the key demand is a reliable and innovative platform for performance and connectivity.
Blade servers provide high performance and maximum redundancy with minimum rack space, power consumption and cabling effort. The Blade Ecosystem BX600 is designed for a
broad range o application areas, from Web server or terminal server farms with lower performance demands all the way to high performance database or application server
configurations. And if your business changes, PRIMERGY blade servers can grow easily to match new demands. They can even change their software configuration during operation if
the load profiles vary. And they can be combined with all other rack-mounted devices without limits.
The PRIMERGY Advanced Blade Ecosystem BX600 is characterized by flexibility, allowing dynamic software reconfiguration and full control with a redundant single point of
administration. The extensive software support for control, management and deployment minimizes administrative costs and frees you from time-consuming tasks to focus on your
business. Our build-to-order process ensures that only fully built and pre-tested solutions are delivered to the customer, tailored to your requirements and ready to grow with your
business needs.
Fujitsu Siemens Computers Price book November 7th 2007
