Page 293

PRIMEPOWER 250

Data Sheets: http://www.fujitsu-siemens.com/primepower

Model

Description

Details

Code

er Price (

)

Comme

Base unit configurations

PRIMEPOWER 250

PW250(F),S10,1x 1.98GHz, no MEM,no Disk

The BC/package comes with :, , 2 processor slots , 1 x 1,98 GHz-CPU included, 4 additional memory slots; max. 16 Gbyte , , 1x
CD/DVD drive ( 10x DVD/40x CD-ROM (speed) ), , 6 PCI slots ( 4 slot 33 MHz, 2 slot 33/66 MHz ), - NO PCI included, 4 HDD
bays, 2 serial ports RJ45, 1 LAN port 10/100/1000 Mbit/s (netboot is supported), 1 LAN port 10/100 Mbit/s (netboot is supported),
1 XSCF Ethernet port 10/100 Mbit/s (netboot is supported), 2 Keyboard/Mouse port ( USB ), 1 RCI port ( RJ11 6-pin ), 1 UPS (
control) port ( DSub 9-pin ), , Redundant Components: Disk Drive (with disk mirroring software or disk array unit), PSU, Fan , Hot
Swap Components: Disk Drive, internal Drive (option), PSU, Fan, , 1 SCSI port for all internal drive bays , for internal bays only,
NOT for external peripheral boxes. The connection between internal SCSI controller and internal bays for storage devices is fix
and cannot be changed.

D:GP250-GR41F10

2937

PW250(F),S9,1x 1.98GHz, no MEM,no Disk

D:GP250-GR41F9

2937

PRIMEPOWER 250N

PW250N(E),S10,1x 1.65GHz, no MEM,no Disk

The BC/package comes with :, , 2 processor slots , 1 x 1,65 GHz-CPU included, 4 additional memory slots; max. 16 Gbyte , , 1x
CD/DVD drive ( 10x DVD/40x CD-ROM (speed) ), , 3 PCI slots ( 2 slot 33 MHz, 1 slot 33/66 MHz ), - NO PCI included, 2 HDD
bays, 2 serial ports RJ45, 1 LAN port 10/100/1000 Mbit/s (netboot is supported), 1 LAN port 10/100 Mbit/s (netboot is supported),
1 XSCF Ethernet port 10/100 Mbit/s (netboot is supported), 2 Keyboard/Mouse port ( USB ), 1 RCI port ( RJ11 6-pin ), 1 UPS (
control) port ( DSub 9-pin ), , Redundant Components: Disk Drive (with disk mirroring software or disk array unit), PSU, Fan , Hot
Swap Components: Disk Drive, internal Drive (option), PSU, Fan, , 1 SCSI port for all internal drive bays , for internal bays only,
NOT for external peripheral boxes. The connection between internal SCSI controller and internal bays for storage devices is fix
and cannot be changed.

D:GP250-GR31E10

1958

PW250N(E),S10,2x1.65GHz,2GB,noDisk,R_PSU The BC/package comes with :, , 2 processor slots , 2 x 1,65 GHz-CPU included, 4 additional memory slots; max. 16 Gbyte , 2GB

incl., 1x CD/DVD drive ( 10x DVD/40x CD-ROM (speed) ), , 3 PCI slots ( 2 slot 33 MHz, 1 slot 33/66 MHz ), - NO PCI included, 2
HDD bays, 2 serial ports RJ45, 1 LAN port 10/100/1000 Mbit/s (netboot is supported), 1 LAN port 10/100 Mbit/s (netboot is
supported), 1 XSCF Ethernet port 10/100 Mbit/s (netboot is supported), 2 Keyboard/Mouse port ( USB ), 1 RCI port ( RJ11 6-pin ),
1 UPS ( control) port ( DSub 9-pin ), , Redundant Components: Disk Drive (with disk mirroring software or disk array unit), PSU,
Fan , Hot Swap Components: Disk Drive, internal Drive (option), PSU, Fan, , 1 SCSI port for all internal drive bays , for internal
bays only, NOT for external peripheral boxes. The connection between internal SCSI controller and internal bays for storage
devices is fix and cannot be changed.

D:GP250-GR35E10

4056

PW250N(F),S10,1x 1.98GHz, no MEM,no Disk

The BC/package comes with :, , 2 processor slots , 1 x 1,98 GHz-CPU included, 4 additional memory slots; max. 16 Gbyte , , 1x
CD/DVD drive ( 10x DVD/40x CD-ROM (speed) ), , 3 PCI slots ( 2 slot 33 MHz, 1 slot 33/66 MHz ), - NO PCI included, 2 HDD
bays, 2 serial ports RJ45, 1 LAN port 10/100/1000 Mbit/s (netboot is supported), 1 LAN port 10/100 Mbit/s (netboot is supported),
1 XSCF Ethernet port 10/100 Mbit/s (netboot is supported), 2 Keyboard/Mouse port ( USB ), 1 RCI port ( RJ11 6-pin ), 1 UPS (
control) port ( DSub 9-pin ), , Redundant Components: Disk Drive (with disk mirroring software or disk array unit), PSU, Fan , Hot
Swap Components: Disk Drive, internal Drive (option), PSU, Fan, , 1 SCSI port for all internal drive bays , for internal bays only,
NOT for external peripheral boxes. The connection between internal SCSI controller and internal bays for storage devices is fix
and cannot be changed.

D:GP250-GR31F10

2867

PW250N(F),S10,2x1.98GHz,2GB,noDisk,R_PSU The BC/package comes with :, , 2 processor slots , 2 x 1,98 GHz-CPU included, 4 additional memory slots; max. 16 Gbyte , 2 GB

D:GP250-GR35F10

6084

PW250N(E),S9,1x 1.65GHz, no MEM,no Disk

D:GP250-GR31E9

1958

PW250N(E),S9,2x1.65GHz,2GB,noDisk,R_PSU

The BC/package comes with :, , 2 processor slots , 2 x 1,65 GHz-CPU included, 4 additional memory slots; max. 16 Gbyte , 2 GB
incl., 1x CD/DVD drive ( 10x DVD/40x CD-ROM (speed) ), , 3 PCI slots ( 2 slot 33 MHz, 1 slot 33/66 MHz ), - NO PCI included, 2
HDD bays, 2 serial ports RJ45, 1 LAN port 10/100/1000 Mbit/s (netboot is supported), 1 LAN port 10/100 Mbit/s (netboot is
supported), 1 XSCF Ethernet port 10/100 Mbit/s (netboot is supported), 2 Keyboard/Mouse port ( USB ), 1 RCI port ( RJ11 6-pin ),
1 UPS ( control) port ( DSub 9-pin ), , Redundant Components: Disk Drive (with disk mirroring software or disk array unit), PSU,
Fan , Hot Swap Components: Disk Drive, internal Drive (option), PSU, Fan, , 1 SCSI port for all internal drive bays , for internal
bays only, NOT for external peripheral boxes. The connection between internal SCSI controller and internal bays for storage
devices is fix and cannot be changed.

D:GP250-GR35E9

4056

PW250N(F),S9,1x 1.98GHz, no MEM,no Disk

D:GP250-GR31F9

2867

PW250N(F),S9,2x1.98GHz,2GB,noDisk,R_PSU

The BC/package comes with :, , 2 processor slots , 2 x 1,98 GHz-CPU included, 4 additional memory slots; max. 16 Gbyte , 2 GB
incl., 1x CD/DVD drive ( 10x DVD/40x CD-ROM (speed) ), , 3 PCI slots ( 2 slot 33 MHz, 1 slot 33/66 MHz ), - NO PCI included, 2
HDD bays, 2 serial ports RJ45, 1 LAN port 10/100/1000 Mbit/s (netboot is supported), 1 LAN port 10/100 Mbit/s (netboot is
supported), 1 XSCF Ethernet port 10/100 Mbit/s (netboot is supported), 2 Keyboard/Mouse port ( USB ), 1 RCI port ( RJ11 6-pin ),
1 UPS ( control) port ( DSub 9-pin ), , Redundant Components: Disk Drive (with disk mirroring software or disk array unit), PSU,
Fan , Hot Swap Components: Disk Drive, internal Drive (option), PSU, Fan, , 1 SCSI port for all internal drive bays , for internal
bays only, NOT for external peripheral boxes. The connection between internal SCSI controller and internal bays for storage
devices is fix and cannot be changed.

D:GP250-GR35F9

6084

PRIMEPOWER 250 Pedestal - 2-way Floorstand Server – Serving your applications with improved uptime
As independently usable system for workgroups or small enterprises the PW 250 can handle almost every business application and gets the job done in time, making use of up to two SPARC64™ V processors, up to 16 GB
main memory and plenty of expansion options in a convenient housing.
PRIMEPOWER 250 2U - 2-way Rack Server – Optimized for low complexity and cost efficiency
PRIMEPOWER 250 2U offers exceptional value for money combining cost efficiency with low complexity computing. The server provides up to two SPARC64™ V processors in a cost cutting housing of two height units, and its
integrated set of redundant components cares for enhanced production uptime.
PRIMEPOWER 250 4U - 2-way Rack Server – Combining the convenience of management and capacities of growth for long lifecycle
The PRIMEPOWER 250 4U is an attractive and compact rack server with reliable features intended for smaller companies as well as departments. Easy to install and manage, the server can help companies realize their
goals without stretching their resources. The cost of managing and deploying systems can be a key decision criterion, so the automated management tools of the PRIMEPOWER 250 are designed to free the system operator
from repetitive activities and potential disruptions, making it easier to manage. The features of the Solaris operating system allow policy-based resource allocation to be set, helping to cut costs and improve application
performance. The system includes the same mainframe-inspired reliability, availability and serviceability (RAS) features as larger models, designed to help keep the applications up and running around the clock. The new fifth
generation of the SPARC64 processors, running at 1.98 GHz clock speed, deliver high performance to run many demanding business applications and still leave room for tomorrow's growth. The server is designed to help
companies do more work with fewer computer systems.

Fujitsu Siemens Computers

Price book November 7th 2007
