PRIMERGY BX620 S3 Data Sheets: http://www.fujitsu-siemens.com/primergy
Model Description Details C
ode
En
d
User Pri
ce (£)
Co
mmen
ts
Base unit configurations
PRIMERGY BLADE BX620 S3
PY BX620 S3 /X 5110/ Server Blade Dual Server Blade equipped with one Dual-Core Intel Xeon processor
for PRIMERGY BX600 S2 (max. 10 server blades), 4 bays for DDR2
533MHz Fully Buffered DIMM PC2-4200F ECC memory modules with
SDDC, 2x 1-channel GBit Ethernet LAN on-board, different
configurable Storage Modules to drive (controller) the internal SATA or
SAS hard disks, 2 bays for 2.5" SATA or SAS HDD`s, RAID1 support
for HDD`s, graphics controller ATI ES1000 16MB on-board. S26361-K921-V611 908 Phased out
PY BX620 S3 /X 5150/ Server Blade Dual Server Blade equipped with one Dual-Core Intel Xeon processor
for PRIMERGY BX600 S2 (max. 10 server blades), 4 bays for DDR2
533/667MHz Fully Buffered DIMM PC2-4200F/5300F ECC memory
modules with SDDC, 2x 1-channel GBit Ethernet LAN on-board,
different configurable Storage Modules to drive (controller) the internal
SATA or SAS hard disks, 2 bays for 2.5" SATA or SAS HDD`s, RAID1
support for HDD`s, graphics controller ATI ES1000 16MB on-board. S26361-K921-V615 1329 Phased out
PY BX620 S3 /X 5160/ Server Blade Dual Server Blade equipped with one Dual-Core Intel Xeon processor
for PRIMERGY BX600 S2 (max. 10 server blades), 4 bays for DDR2
533/667MHz Fully Buffered DIMM PC2-4200F/5300F ECC memory
modules with SDDC, 2x 1-channel GBit Ethernet LAN on-board,
different configurable Storage Modules to drive (controller) the internal
SATA or SAS hard disks, 2 bays for 2.5" SATA or SAS HDD`s, RAID1
support for HDD`s, graphics controller ATI ES1000 16MB on-board. S26361-K921-V616 1475 Phased out
PY BX620 S3 /X 5148/ Server Blade Dual Server Blade equipped with one Dual-Core Intel Xeon processor
for PRIMERGY BX600 S2 (max. 10 server blades), 4 bays for DDR2
533/667MHz Fully Buffered DIMM PC2-4200F/5300F ECC memory
modules with SDDC, 2x 1-channel GBit Ethernet LAN on-board,
different configurable Storage Modules to drive (controller) the internal
SATA or SAS hard disks, 2 bays for 2.5" SATA or SAS HDD`s, RAID1
support for HDD`s, graphics controller ATI ES1000 16MB on-board. S26361-K921-V617 1214 Phased out
PY BX620 S3 /X E5310/ Server Blade Dual Server Blade equipped with one Quad-Core Intel Xeon processor
for PRIMERGY BX600 S2 (max. 10 server blades), 4 bays for DDR2
533MHz Fully Buffered DIMM PC2-4200F ECC memory modules with
SDDC, 2x 1-channel GBit Ethernet LAN on-board, different
configurable Storage Modules to drive (controller) the internal SATA or
SAS hard disks, 2 bays for 2.5" SATA or SAS HDD`s, RAID1 support
for HDD`s, graphics controller ATI ES1000 16MB on-board. S26361-K921-V710 929 Phased out
PRIMERGY BX620 S3 - Dual-socket Intel® Xeon® server blade
Newest processors 1 – 2 Quad-Core Intel® Xeon® 5300 series from 1.60 up to 2.66 GHz and Dual-Core Intel® Xeon®; 5000 series from 3.00 up
to 3.73 GHz and 5100 series from 1.60 up to 3.00 GHz with Front side bus frequencies from 667 up to
1333 MHz; Chipset Intel® 5000P
(Blackford); FBD 533MHz, 4x2 DIMM sockets, 2 banks with 2 channels each, 2 memory controllers; memory mirroring mode and SDDC support;
2x Gigabit LAN ports via midplane at GbE switch or Pass-Thru blade; 1x VGA and 2x USB at the front via special cable; connection to the
advanced KVM switch via the midplane; optional via midplane at FC or GbE switch or Pass-Thru blade: 2x 2-Gbit FibreChannel or 2x 1-Gbit
Ethernet port; SAS (LSI 1068) - 2-channel SAS (RAID level 1) as pluggable storage module; SATA (from ESB2) - 2-channel SATA (RAID level 1)
as pluggable storage module; Graphics ATI ES1000, 16Mbyte RAM; LAN (BCM5708) - 2x 1-channel Gbit Ethernet controller, - TOE, iSCSI and
RDMA optional; Server management Baseboard management controller (BMC).
Fujitsu Siemens Computers Price book November 7th 2007
