Page 32
Deutsch 12 Pin Connector (For reference only: See drawing HN0389 for details of harness)
Pin Function HN0389 Wire Color
1 Power Out to Faria Bus Instruments Red
2 Faria Bus Signal A-Y White
3 Faria Bus Signal B-Z Green
4
Ground In (and ground to Faria Bus
Instruments)
Black
5 Power In (+14 V from Ignition) Violet
6 Fuel Sender In Pink
7 Trim Sender In Blue / White
8 NMEA CAN Power Ground Black
9 NMEA CAN Power Red (Micro-C cable)
10 NMEA CAN Shield (if present) Shld (Micro-C cable)
11 NMEA CAN Low In White (Micro-C cable)
12 NMEA CAN High In Blue (Micro-C cable)
Deutsch 6 Pin Connector (For reference only: See drawing HN0401 for details of harness)
Pin Function HN0401 Wire Color
1 N/C
2 N/C
3 NMEA 0183 A (+) Red / White
4 NMEA 0183 B (-) Red / Blue
5 N/C
6 N/C
