Farallon Communications QMS 4525 - Manual (Page 107)

Clearing Paper
Jams
6-7 Troubleshooting
2 &DXWLRQ,IWKHPDQXDOIHHGSODWHLVQRWUHSODFHGSDSHUFDQPLVIHHGFDXVLQJ
DQRWKHUSDSHUMDP
When You Have Finished
Once all jammed paper has been removed, press the Continue key
on the control panel. The printer then resumes printing, starting with
those jobs not properly deposited in the standard output bin when the
jam occurred. You must then reprint any damaged pages.
• 1RWH,IWKHVDPHSDSHUMDPRFFXUVRIWHQPDNHVXUH\RXDUHXVLQJDSDSHU
VL]HDQGZHLJKWWKDWLVVXSSRUWHGE\WKHSULQWHU7KHQVHHWKDWWKHSDSHULV
FRUUHFWO\VWDFNHGLQWKHSDSHULQSXWELQRUDOLJQHGLQWKHPDQXDOIHHGVORW
DQGPDNHVXUHWKHFORVXUHSODWHLVFRUUHFWO\SRVLWLRQHGDQGDOLJQHGDJDLQVW
WKHULJKWKDQGHGJHRIWKHSDSHUVWDFN
4 If jammed paper cannot
be removed from the
duplex unit as described
in the previous step,
remove the manual feed
plate.
Grasp the plate using the
two holes in the center
and pull it slightly up and
then out.
5 Remove any jammed
paper, and replace the
manual feed plate.
