5. MENU OPERATION
5-5
5.3.2 Changing setting of preset key
1. Choose PRESET KEY following the procedure in paragraph 5.3.1.
2. Press the [MENU] key to open the menu.
3. Press
▲ to choose MENU, and then press ◄ or ► to choose PRESET.
MODE SECTOR TRAIN RANGE TILT SPEED
PRESENT
CUSTOM1
CUSTOM2
CUSTOM3
FUNCTION KEY: ENTRY MENU: END
ADJUST THE KNOBS AND FUNCTION KEYS TO THE DESIRED SETTING,
THEN PRESS A CUSTOM MODE KEY TO SAVE THE SETTING.
240
°
360 °
180
°
360
°
160
160
120
160
FAST
FAST
FAST
NORM
30
°
30 °
90
°
30
°
0
°
0 °
90
°
0
°
MENU COM1 HORZ VERT ES PRESET SYS COM2
PRESET menu
4. Set the [MODE], [SECTOR], [TRAIN], [RANGE], [TILT] and [FAST SCAN] controls
according to target fish or fishing area. Current setting is shown in the “PRESENT”
section.
5. Press the CUSTOM MODE keys [1], [2] or [3] as appropriate to program. You are
asked if you want to save the settings to the custom key pressed. (In the example
below the custom key [1] was pressed.)
: CHANGE MENU: END
SAVE THE SETTINGS TO CUSTOM1 KEY?
NO YES
6. Press ► to choose YES.
7. Press the [MENU] key. The message “PRGM SET” appears at the screen top.
8. Press the [MENU] key to finish.
Activating a custom mode key
1. Press appropriate CUSTOM MODE key. The indication CUSTOM1, CUSTOM2 or
CUSTOM3 appears at the top of the screen depending on key pressed.
2. To escape from the custom mode operation, operate any of the following controls:
[MODE], [SECTOR], [TRAIN], [RANGE], [TILT] or [FAST SCAN].
