5. MENU OPERATION
5-3
5.3 Short-cut Menu, Preset Menu
These menus program the CUSTOM MODE keys [1], [2] and [3]. The menu to use may
be chosen with CUSTOM KEY on the SYSTEM SETTING 1 menu.
Short-cut key: One-touch activation of the operator-selected dialog box.
Preset key: One-touch setup of mode, sector, train, range, tilt and scan speed. Below
are the default settings for PRESET.
Custom mode key default settings for PRESET
CUSTOM MODE key Display Mode Sector Train Range (m) Tilt Speed
Key 1
Horizontal
Expansion
240 ° 0 ° 160 30 ° Fast
Key 2 Horizontal 360 ° 0 ° 160 30 ° Fast
Key 3 Vertical Scan 180 ° 90° 120 90° Fast
5.3.1 Choosing short-cut or preset
1. Press the [MENU] key to open the menu.
2. Press ▲ to choose MENU, and then press ► to choose SYS.
NO YES
: SELECT : CHANGE MENU: END
GO TO SYS MENU
MENU COM1 HORZ VERT ES PRESET COM2 SYS
Display for opening system menu
3. Press ▼ to choose GO TO SYS MENU.
4. Press ◄ to choose YES.
