AN-2030: Digital Diagnostic Monitoring Interface for Optical Transceivers
F i n i s a r
9/26/02 Revision D Page 6
1
TABLE 3.3: Connector values 2
Value Description of connector
00h Unknown or unspecified
01h SC
02h Fibre Channel Style 1 copper connector
03h Fibre Channel Style 2 copper connector
04h BNC/TNC
05h Fibre Channel coaxial headers
06h FiberJack
07h LC
08h MT-RJ
09h MU
0Ah SG
0Bh Optical pigtail
0C-1Fh Reserved
20h HSSDC II
21h Copper Pigtail
22h-7Fh Reserved
80-FFh Vendor specific
