AN-2030: Digital Diagnostic Monitoring Interface for Optical Transceivers
F i n i s a r
9/26/02 Revision D
Page 14
Table 3.8: Diagnostic Monitoring Type
1
Data Address
Bits
Description
92
7
Reserved for legacy diagnostic
implementations. Must be ‘0’ for compilance
with this document.
92
6
Digital diagnostic monitoring implemented
(described in this document). Must be ‘1’ for
compliance with this document.
92
5
Internally Calibrated
92
4
Externally Calibrated
92
3
Received power measurement type
0 = OMA, 1 = Average Power
92
2
Address change required see section above,
“addressing modes”
92
1-0
Reserved
