Contents

C141-E203-01EN xi

4.6.4

Digital PLL circuit ..............................................................................4-11

4.7 Servo Control ..........................................................................................4-12

4.7.1

Servo control circuit............................................................................4-12

4.7.2

Data-surface servo format...................................................................4-14

4.7.3

Servo frame format .............................................................................4-16

4.7.4

Actuator motor control........................................................................4-17

4.7.5

Spindle motor control..........................................................................4-18

CHAPTER 5

Interface ..................................................................................... 5-1

5.1 Physical Interface ......................................................................................5-2

5.1.1

Interface signals ....................................................................................5-2

5.1.2

Signal interface regulation ....................................................................5-4

5.1.2.1

Out of band signaling..........................................................................5-4

5.1.2.2

Primitives

descriptions

......................................................................5-5

5.1.3

Electrical specifications ........................................................................5-6

5.1.4

Connector pinouts .................................................................................5-8

5.2 Logical Interface........................................................................................5-9

5.2.1

Communication layers ........................................................................5-10

5.2.2

Outline of the Shadow Block Register................................................5-11

5.2.3

Outline of the frame information structure (FIS)................................5-12

5.2.3.1

FIS types ...........................................................................................5-12

5.2.3.2

Register - Host to Device ..................................................................5-12

5.2.3.3

Register - Device to Host ..................................................................5-13

5.2.3.4

DMA Active - Device to Host ..........................................................5-13

5.2.3.5

DMA Setup - Device to Host or Host to Device (Bidirectional)......5-14

5.2.3.6

BIST Active - Bidirectional ..............................................................5-15

5.2.3.7

Data - Host to Device or Device to Host (Bidirectional)..................5-16

5.2.4

Shadow block registers .......................................................................5-17

5.3 Host Commands ......................................................................................5-22

5.3.1

Command code and parameters ..........................................................5-22
