7. CUSTOMIZING YOUR UNIT
7-17
CHART CONFIGURATION menu description
CHART CONFIGURATION menu description
Object Content Settings Description
ON Turns perspective display on. PERSPECTIVE Perspective
display on/off OFF Turns perspective display off.
ON Removes overlapping objects from display. DE-CLUTTER Overlapping
object on/off OFF Displays overlapping objects.
FULL All chart attributes are displayed.
SIMPLE Some attributes such as SEABED TYPE,
TRACKS and ROUTES are displayed.
FISHING Setting for use in fishing.
LOW Only NAV AIDS and water depth are
shown.
CHART DISPLAY
MODE Choose chart
display mode
CUSTOM User chooses which chart attributes to turn
on or off.
ON Safety status ON (See Safety Status
Indication on page 7-18 for description.) SAFETY STATUS* 1 Safety status
indication
OFF Safety status OFF
PLOT/OVERLAY Shown on plotter and overlay displays.
PLOT Shown on plotter display.
WAYPOINT Waypoints marks
and waypoint
names
OFF Waypoint markers and waypoint names
are turned off. Waypoint names are not
displayed regardless if WAYPOINT NAME
(below) is set to ON.
PLOT/OVERLAY Shown on plotter and overlay displays.
PLOT Shown on plotter display.
WAYPOINT NAME Waypoint names
OFF Waypoint names are turned off.
PLOT/OVERLAY Shown on plotter and overlay displays.
PLOT Shown on plotter display.
NAMES Text for land and
sea areas
OFF Names are turned off.
PLOT/OVERLAY Shown on plotter and overlay displays.
PLOT Shown on plotter display.
BUOYS NAME Name of buoys
OFF Buoy names are turned off.
US NOAA symbols are shown.
US SIMPLE Complex object shown with single icon.
INT International symbols are shown.
INT SIMPLE Complex object shown with single icon.
PLOT/OVERLAY Shown on plotter and overlay displays.
PLOT Shown on plotter display.
NAV-AIDS Lighthouses,
buoys, etc.
OFF Navaids are turned off.
ON Light sectors displayed. LIGHT SECTORS Light sector
FLASHING Light sectors displayed and flashing.
PLOT/OVERLAY Shown on plotter and overlay displays.
PLOT Shown on plotter display.
ATTENTION
AREAS Attention areas
OFF Attention areas are turned off.
PLOT/OVERLAY Shown on plotter and overlay displays.
PLOT Shown on plotter display.
TIDES &
CURRENTS Tidal station and
current station
OFF Tidal station and current station are not
shown. Tidal graph is also turned off.
(Con’t on next page.)
