1-6
Steering Display
The steering display provides steering information such as range, bearing and ETA to desti-
nation, course, and speed.
2D MAG
nm
CSE:
60
°
SPD:
12.5
kt
W 300 330 N 30 60 E
04:32
Bearing scale
Bearing reference (magnetic)
Speed
I I I I I I I I I I I I I
354
°
RNG: BRG:
TTG: ETA:
9.0
1H30M 12:30
CURSOR
Range from own ship to
destination
Bearing from own ship
to destination
Estimated Time of
Arrival at destination
Receiver status
Bearing
Time-To-Go to
destination
Own ship mark
Course
Time
Figure 1-7 Steering display
Nav Data Display
The Nav Data display shows position in latitude and longitude (or TDs), course, speed, date
and time.
2D
CSE: SPD:
12.5
kt
34
°
44.000'
135
°
21.000'
12–DEC–97 16 :44 :15
N
E
Date and time
Course Speed
7
°
Position in latitude
and longitude
Receiver status
Figure 1-8 Nav data display
