L06 SIZE PUMPS
VALVE TYPE VALVE ASSY VALVE SIZE REMOVAL TOOL
INSTALLATION
TOOL
Disc 5257290 1.312 G.L. / .94 ID P534695 (Small Ball) P534699
Disc 5257291 1.437 G.L. / .94 ID P534695 (Small Ball) P534702
Disc 5272584 1.312 G.L. / .94 ID P534695 (Small Ball) P534699
Disc 5272585 1.437 G.L. / .94 ID P534695 (Small Ball) P534702
Disc P506665 1.437 G.L. / .94 ID P534695 (Small Ball) P534702
Disc P506666 1.312 G.L. / .94 ID P534695 (Small Ball) P534699
L09 SIZE PUMPS
VALVE TYPE VALVE ASSY VALVE SIZE REMOVAL TOOL
INSTALLATION
TOOL
Disc 1256641 1.186 G.L. / .75 ID P504436 OR P534695 P534696
L11 & L12 SIZE PUMPS
VALVE TYPE VALVE ASSY VALVE SIZE REMOVAL TOOL
INSTALLATION
TOOL
Disc 1278104 1.563 G.L. / 1.09 ID P534694 (Large Ball) P534699 OR P534702
Disc 5255419 1.563 G.L. / 1.23 ID P534694 (Large Ball) P534699 OR P534702
Disc 5257585 1.563 G.L. / 1.23 ID P534694 (Large Ball) P534699 OR P534702
L16 SIZE PUMPS
VALVE TYPE VALVE ASSY VALVE SIZE REMOVAL TOOL
INSTALLATION
TOOL
Disc 5255419 1.563 G.L. / 1.23 ID P534694 (Large Ball) P534699 OR P534702
Disc 5257585 1.563 G.L. / 1.23 ID P534694 (Large Ball) P534699 OR P534702
NOTE: G.L. = Gage Line
Table 8: Disc Valve Removal and Installation Tool Guide
