Quantities for Each Model
Item
No.
Component
Description
L06 &
HD
L09
L09 HD
L11 & HD
L12
L16
48
Gasket, Power End
3
3
3
3
3
3
49
Valve Cover
3
3
3
3
3
3
50
O-Ring, Valve Cover
3
3
3
3
3
3
51
Clamp, Valve Cover
NA
NA
NA
3
3
3
52
Stud, Valve Cover
NA
NA
NA
6
6
6
53
Hex Nut, Valve Cover
NA
NA
NA
6
6
6
54
Cylinder Cover
3
3
3
3
3
3
55
O-Ring, Cylinder Cover
3
3
3
3
3
3
56
Back Up Ring
NA
NA
NA
3
3
3
57
Clamp, Cylinder Cover
3
3
3
3
3
3
58
Stud, Cylinder Cover
6
6
6
6
6
6
59
Stud, Fluid Cylinder
2
2
2
2
2
2
60
Flat Washer
8
8
8
8
8
6
61
Hex Nut
10
8
8
8
8
8
62
Pipe Plug, Drain
NA
NA
NA
4
4
4
63
Plug Suction
3
3
3
3
3
3
†
Some bearing covers are sealed with gaskets and others use o-rings
*
Some piston holders are grooved for the o-ring, and others require a seal holder
that is situated on the rod before the piston holder with the o-ring groove facing
the piston holder.
