Quantities for Each Model
Item
No.
Component
Description
L06 & HD
L09
L09 HD
L11 & HD
L12
L16
1
Power Frame
1
1
1
1
1
1
2
Crankshaft
1
1
1
1
1
1
3
Pinion Shaft
NA
1
NA
1
NA
1
4
Connection Rod Assembly
3
3
3
3
3
3
5
Rod Bearing
6
6
6
6
6
6
6
Wrist Pin
3
3
3
3
3
3
7
Crosshead Assembly
3
3
3
3
3
3
8
Seal Holder
3
3
3
3
3
3
9
Oil Seal, Piston Rod
6
9
9
9
9
9
10
Seal Retainer Nut
NA
3
3
3
3
3
11
Gasket, Seal Retainer
NA
3
3
3
3
3
12
Bearing Housing, Blind
1
1
1
2
1
2
13
Shim, Bearing Housing
6
12
12
6
6
6
14
Gasket, Bearing Housing †
2
2
2
2
2
2
15
Back Cover
1
1
1
1
1
1
16
Gasket, Back Cover
1
1
1
1
1
1
17
Pinion Housing, Drive
NA
1
NA
1
NA
1
18
Pinion Housing, Blind
NA
1
NA
1
NA
1
19
Oil Seal, Rotating
1
1
1
1
1
1
20
Gasket, Pinion
NA
2
NA
2
NA
1
21
Shim, Pinion
NA
NA
NA
NA
NA
8
22
Bearing Cone, Crank
2
2
2
2
2
2
23
Bearing Cup, Crank
2
2
2
2
2
2
24
Bearing Cone, Pinion
NA
2
NA
2
NA
2
25
Bearing Cup, Pinion
NA
2
NA
2
NA
2
26
Key
1
1
1
1
1
1
27
Set Screw
3
6
6
6
6
6
28
Cap Screw, Bearing Housing
6
12
12
10
12
20
29
Cap Screw, Back Cover
12
14
16
20
16
23
30
Cap Screw, Plate
NA
2
NA
2
NA
2
31
Plate, Inspection
NA
1
NA
1
NA
1
32
Pipe Plug, Power End
2
2
2
2
2
5
33
Filler Cap or Vent
1
1
1
1
1
1
34
Nameplate
1
1
1
1
1
1
35
Tapping Screw
2
2
2
2
2
2
36
Bearing Housing, Drive
1
1
1
0
1
0
37
Fluid Chamber
1
1
1
1
1
1
38
Valve Assembly
6
6
6
6
6
6
39
Cylinder
3
3
3
3
3
3
40
Piston Cup
3
3
3
3
3
3
41
Piston Holder
3
3
3
3
3
3
42
Hex Nut
3
3
3
3
3
3
43
Plunger Nut
3
3
3
3
3
3
44
Piston Retainer
3
3
3
3
3
3
45
O-Ring, Rod Seal *
3
3
3
3
3
3
46
O-Ring, Fluid Cylinder
NA
NA
NA
3
3
3
47
Ring Seal
3
3
3
3
3
3
