KSCFH18E COOL ZONE SERIES ELECTRIC FRYERS
CHAPTER 8: PARTS LIST
8-13
8.1.7 Oil Return Components (cont.)
Item # Part # Description
1 823-3344 Handle, Actuator- Oil Return Valve
2 809-0843 Pin, Cotter- Plated
3 809-0885 Washer, 3/8 x 1 x .083" Type A Plain
4 823-3238 Handle, Oil Return Activate
5 816-0548 Cap, Vinyl- Yellow, Oil Return Handle
6 813-0173 Union, ½" NPT BM
7 813-0022 Nipple, ½" x Close NPT BM
8 813-0634 Elbow, Reducing- ½ x 3/8" x 90° NPT BM
9 813-0644 Nipple, 3/8 x 1-½" NPT BM
10 810-2125 Valve, Ball- Oil Return, 3/8"
11 813-0625 Nipple, 3/8" x Close NPT BM
12 813-0006 Bushing, Reducing- ½ x 3/8" NPT BM
13 813-0706 Elbow, Street- ½" x 90° NPT BM
14 813-0062 Elbow- ½" x 90° NPT BM
15 813-0622 Nipple, ½ x 1-½" NPT BM
16 813-0247 Nipple, ½ x 3-½" NPT BM
17 813-0003 Tee, ½" NPT BM
18 813-0654 Nipple, ½ x 4" NPT BM
19 813-0156 Plug, Pipe- ½" NPT BM
20 813-0672 Nipple, ½ x 8" NPT BM
21 106-0893SP Bracket Assembly- Oil Return Microswitch- RH
22 810-2144 Spacer, Aluminum- ¼ O.D. x 3/8"
23 807-2104 Microswitch, Oil Return
24 809-0846 Screw, 4-40 x 1" Slotted Head
25 826-1366 Nut, 4-40 Keps External Tooth (Qty: 25)
26 200-1341 Bracket, Oil Return Handle
27 826-1371 Screw, #8 x ½" (Qty: 25)
* Not Illustrated
