KSCFH18E COOL ZONE SERIES ELECTRIC FRYERS
CHAPTER 8: PARTS LIST
8-11
8.1.6 Filter Pan, Pump Motor and Related Components (cont.)
Item Part # Description
1 823-3240 Pan, Filter
2 810-2119 Grid, Filter
3 803-0170 Paper, Filter
* 803-0002 Filter Powder
4 823-3201 Ring, Hold-Down (No Handles)
* 823-3202 Handle, Hold-Down Ring
5 823-3204 Crumb Basket
6 823-3241 Lid, Filter Pan- Front
7 210-1295 Lid, Filter Pan- Back
* 810-2105 Handle, Pan Lid, Front and Back- Chrome
* 809-0918 Screw, 10-24 x ½" Slotted (Use With 810-2105)
* 809-0191 Washer, ¼ Spring-Lock (Use With 810-2105)
8 809-0866 Screw, SS- ¼-10 x ½" Phillips Head
9 210-1293 Insert, Mounting Plate- Caster
10 810-2141 Caster, 2"
11 809-0823 Nut, Nylock- ¼-20
12 809-0822 Bolt, ¼-20 x ½" Hex Head
13 813-0679 Plug, SS- 1/8 Square Head
14 810-2100 Motor, Filter Pump
15 810-2098 Pump, Filter- 8GPM
16 Fitting, Oil Suction Start
* 813-0022 Nipple, ½" NPT x Close BM
* 813-0003 Tee, ½" NPT BM
* 813-0156 Plug, Hex Head ½" NPT BM
17 813-0703 Nipple, ½ x 7-¾" NPT BM
18 813-0062 Elbow, ½" x 90° NPT BM
19 813-0265 Nipple, ½ x 2-½" NPT BM
20 813-0173 Union, ½" NPT BM
21 813-0683 Nipple, ½ x 6" NPT BM
22 813-0608 Coupling, Full
23 823-3546 Nipple/Plate Assembly- KFC18E
24 810-0697 Disconnect, Male
* 826-1392 O-Ring, Disconnect (Qty: 5)
25 106-0820SP Drip Cup Assembly
* 803-0209 Brush, Frypot
* Not Illustrated
