KSCFH18E COOL ZONE SERIES ELECTRIC FRYERS
CHAPTER 8: PARTS LIST
8-9
8.1.5 Frypot and Drain Components (cont.)
Item Part # Description
1 816-0547 Cap, Vinyl- Red
2 823-3224 Handle, Drain Valve
3 200-1257 Retainer, Drain Valve Nut
4 812-0442 Insulation, Microswitch
5 826-1366 Nut, 4-40 Keps Hex With External Tooth (Qty: 25)
6 807-2104 Microswitch, Roller
7 823-3236 Valve, Drain- With Washers, Nut and Bracket
8 813-0687 Nipple, SS- 1-½" x Close
9 823-3221 Elbow With Bracket, Drain- Left
10 823-3222 Elbow With Bracket, Drain- Right
11 823-3456 Drain Pipe- Left
12 823-3358 Drain Pipe- Right
13 809-0123 Screw, 10-32 x ¾" Slotted Head
14 826-1376 Nut, Keps- 10-32 Hex (Qty: 10)
15 210-2311 Clamp, Center- Drain Pipe
16 823-3235SP Frypot, SS- KSCFH18E
17 106-0960SP Switch, Float Safety
