5.3.4 Map Descriptor Example.
Map_Descriptor_Name , Scan_Interval , Data_Array_Name , Data_Array_Offset , Function , Node_Name , Secutron_Type , Secutron_Circuit , Length
P1_POLLER , 0s , Poller , 0 , Rdbc , Node_1 , Poller , - , 1
P1C1_DEVICES , - , P1C1_DEVICES , 0 , Passive_Client , Node_1 , Device , 1 , 200
P1C1_FUNCTION , - , P1C1_FUNCTION , 0 , Passive_Client , Node_1 , Function , 1 , 200
P1C69_RESTART , - , P1C69_RESTART , 0 , Passive_Client , Node_1 , Device , 69 , 100
P1C69_FUNCTION , - , P1C69_FUNCTION , 0 , Passive_Client , Node_1 , Function , 69 , 100
P1C90_RESET , - , P1C90_RESET , 0 , Passive_Client , Node_1 , Device , 90 , 100
P1C90_FUNCTION , - , P1C90_FUNCTION , 0 , Passive_Client , Node_1 , Function , 90 , 100
.
Any unique
name. Name
will appear in
Bridge Map
Descriptor
status
information
screens.
The rate at which the
driver polls the panel.
A Data Array name
must be one found
under Data_Arrays.
Data from a circuit
event will be stored in
the array at
Data_Array_Offset.
The Poller Data Array
will contain non-zero
data when
communications with
the panel is OK
Function must be
read for pollers and
all others
Passive_Client. A name given
to the device to
which the
FieldServer is
connected.
The type of data the
Map Descriptor
points to. Device
data contains alarm
statuses. Function
data contains
condition codes.
Refer to Appendix
B.1 for more
information. The circuit or
zone number
used to trap
incoming events
into the Map
Descriptor. See
Driver notes.
The number of devices
on the circuit this Map
Descriptor can detect
for incoming events.
