Appendix B. Reference
Appendix B.1. Event Function or Condition Codes
When the Client driver receives an event from the panel, it stores the event’s function or condition code in the
Secutron_Type=function Map Descriptor’s Data Array at the device number’s offset,
Example:
Device=3 on Circuit=1 goes into alarm – the Panel reports an event with function code A (Decimal 65)
The Map Descriptor Secutron_Type=device, Secutron_Circuit=1 will set a bit and store the event function
code A (Decimal 65) at offset 3 in the Map Descriptors’ Data Array.
The Secutron_Type=device Map Descriptors will set a bit if any of the events listed below occur on that
circuit or zone. The bit will be cleared if the panel reports the event as cleared.
The following table lists the full list of event function codes
ASCII value Decimal Meaning
A
65 Alarm
B 66 Bypass
C 67 Comlink
D 68 Duplicate Addressable Device
E 69 Maintenance Alert
G 71 Ground Fault
H 72 Hot Key Pressed
I 73 Illegal Addressable Device
J 74 Switch
M 77 Missing Addressable Device
N 78 Non-Fire/Non-Reporting
P 80 Pull Station Alarm
Q 81 Releaser Abort
R 82 Releaser Halt
S 83 Supervisory
T 84 Trouble or Parameter Change
U 85 Wrong Device Type
W 87 Waterflow Alarm
