5 CONFIGURING THE FIELDSERVER AS A SECUTRON MODUL-R DRIVER CLIENT
For a detailed discussion on FieldServer configuration, please refer to the FieldServer Configuration Manual. The
information that follows describes how to expand upon the factory defaults provided in the configuration files
included with the FieldServer (See “.csv” files on the provided with the FieldServer).
This section documents and describes the parameters necessary for configuring the FieldServer to communicate
with Secutron Modul-R panels.
The configuration file tells the FieldServer about its interfaces, and the routing of data required. In order to enable
the FieldServer for Secutron Modul-R driver communications, the driver independent FieldServer buffers need to
be declared in the “Data Arrays” section, the destination device addresses need to be declared in the “Client Side
Nodes” section, and the data required from the Servers needs to be mapped in the “Client Side Map Descriptors”
section. Details on how to do this can be found below.
Note that in the tables, * indicates an optional parameter, with the bold legal value being the default.
5.1 Client Side Connection Parameters
Section Title
Connections
Column
Title
Function Legal Values
Port
Specify through which port the device is connected to
the FieldServer
P1-P8 1
Baud* Specify baud rate
150, 300, 1200, 2400, 4800, 9600
(Vendor limitation)
Parity* Specify parity None (Vendor limitation)
Data_Bits* Specify data bits 8 (Vendor limitation)
Stop_Bits* Specify stop bits 1 (Vendor limitation)
Protocol Specify protocol used Secutron
Example
// Client Side Connections
Connections
Port , Protocol
, Baud , Parity , Handshaking
P1 , Secutron , 9600 , None , None
1 Not all ports shown are necessarily supported by the hardware. Consult the appropriate Instruction manual for details of the ports available
on specific hardware.
