5.2 Client Side Node Parameters
Section Title
Nodes
Column Title Function
Legal Values
Node_Name Provide name for Node Up to 32 alphanumeric characters
Node_ID Generic Node ID unique to port. Also used as panel number. 0-999
Protocol Specify protocol used Secutron
Port Specify which port the device is connected to the FieldServer P1-P8 1
Example
// Client Side Nodes
Nodes
Node_Name , Node_ID , Protocol , Connection
Node_1 , 1 , Secutron , P1
5.3 Client Side Map Descriptor Parameters
5.3.1 FieldServer Specific Map Descriptor Parameters
Column Title Function Legal Values
Map_Descriptor_Name Name of this Map Descriptor Up to 32 alphanumeric characters
Data_Array_Name
Name of Data Array where data is to be
stored in the FieldServer One of the Data Array names from
Section 4
Data_Array_Offset Starting location in Data Array
0 to (Data_Array_Length-1) as specified
in Section 4
Function Function of Client Map Descriptor Rdbc, Passive_Client
Node_Name Name of Node to fetch data from
One of the node names specified in
Section 5.2.
5.3.2 Driver Specific Map Descriptor Parameters
Column Title Function Legal Values
Secutron_Type Identifies the type of data the Map Descriptor points to
Poller, Device,
Function
Secutron_Circuit Identifies the circuit or panel zone 0-99
Length
The number of devices on the circuit the Map Descriptor must
detect
0-999
5.3.3 Timing Parameters
Column Title Function Legal Values
Scan_Interval Rate at which data is polled >= 0s
