6-5
6 Select “Portrait” or “Landscape” by
pressing or . Then press . The
scanner displays Screen 4.
7 Select Size by pressing or . Then
press . The scanner displays
Screen 5.
8 Select Resolution by pressing or .
As the cursor moves to left 100/150 may
appear. Then press
. The scanner
displays Screen 6.
9 Select Front Density by pressing or
. As the cursor moves to right, /
may appear. Then press Enter.
Scanner displays Screen 7.
Density display
Without IPC With IPC-4D Descreption
option option
Very dark
Dark
AT1 * Dynamic Threshold (DTC mode)
AT2 * Simplified Dynamic Threshold (IPC mode)
Normal
Light
Very light
* This parameter appears only when IPC-4D is installed.
