1-3
No.
Function
1
Document cover
Closes over and keeps in place document to be read.
2
Document bed
Holds document to be read. Also called the Flatbed (FB).
3
Document holding pad
Presses a document to the Document bed.
4
Automatic document feeder (ADF)
Automatically feeds documents to the reading position.
5
Stacker
Stacks the read documents.
6
Power switch
Turns the power on or off.
7
Operator panel
Contains indicator panel that indicates scanner status.
8
ADF paper chute
Holds documents to be fed by the automatic document
feeder (ADF).
9
ADF lever
Opens or closes ADF to enable removal of documents
jammed in the feeder.
10
Power inlet
Connects to an AC power outlet with the power cable.
11
Interface connectors
Connects to the host system with interface cables.
12
Third party slot
A Fujitsu Video Interface Option Board is installed.
