Page 44
Installation Requirements
4-2
C141-E237
4.1.2 Mounting
orientations
The permissible orientations of the HDDs are shown in Figure 4.2, and the tolerance of the angle is
±5° from the horizontal plane.
(a) Horizontal –1
(b) Horizontal –2
(c) Vertical –1
(d) Vertical –2
(e) Upright mounting –1
(f) Upright mounting –2
Figure 4.2
HDD orientations
Direction of gravity
