• Carefully fit the battery into the battery compartment.
2
Power Wheels
®
12 Volt Battery
BATTERY INSTALLATION
IMPORTANT! Use only a Power Wheels
®
12 volt battery.
Use of any other battery will damage your vehicle.
• Press the battery door button on the back end of
the vehicle.
• Lower the battery door.
1
• Plug the motor harness connector into the battery.
Push firmly.
• Lift the battery door and
"snap" into place.
3
4
Battery Door
Motor Harness
Battery Door
