fi-5530C Image Scanner Getting Started 9
5. Click [INSTALL PRODUCTS].
6. Click [ISIS Driver] on the window below.
7. Error Recovery Guide Installation window
appears.
Error Recovery Guide is a software that dis-
plays troubleshooting information on screen if
any scanner error occurs. Although this soft-
ware’s installation is highly recommended, it
can be installed later if you do not install it in
this step.
8. Select a language used for installation on
[Choose Setup Language] window and click
[OK].
9. Install the application following the instructions
on the window.
10. When the [InstallShield Wiizard Complete] win-
dow appears, click [Finish].
Your computer will be restarted and the scanner will be
detected. Do not remove the Setup
CD-ROM from the CD drive until your PC has com-
pletely restarted.
The installation of the scanner driver is completed.
■ Installing QuickScan Pro
TM
"QuickScan Pro TM " is an image capturing software that
complies with the ISIS standard.
1. Insert the Setup CD-ROM into a CD drive.
⇒
appears.
2. Click [INSTALL PRODUCTS]. ATTENTION
When you select [Yes] for installing Error
Recovery Guide, the [Choose Setup Lan-
guage] window appears. Select a lan-
guage and follow the instructions on the
window. The Error Recovery Guide will
automatically continue finishing its installa-
tion. Please wait until the installation of
TWAIN driver automatically starts.
ATTENTION
Depending on the OS, the following oper-
ations may be necessary.
For Windows 98:
When a request for inserting the CD-ROM
of Windows 98 appears, insert it into the
CD drive and click [OK].
For Windows 2000:
When [Digital Signature not Found]
appears, click [Yes].
ATTENTION
When using Windows NT 4.0, Windows
2000 or Windows XP, log on as a user with
"Administrator" privileges.
