18

INC

A:

CALIBRATE

< INC > < LRV >

1

CL

ENT

2

A-1:

CALIBRATE
LRV

ЧЧЧ

.

ЧЧ

%

CHNG OK? < ENT/CL >

3

A-2:

CALIBRATING

LRV

ЧЧЧ

.

ЧЧ

%

4

A-1:

CALIBRATE

LRV

ЧЧЧ

.

ЧЧ

%

< ENT > < CL >

ENT

ЧЧЧ

.

Ч

kPa

ЧЧЧ

.

Ч

kPa

ЧЧЧ

.

Ч

kPa

5

A-3:

CALIBRATE
URV

ЧЧЧ

.

ЧЧ

%

CHNG OK? < ENT/CL >

6

A-4:

CALIBRATING

URV

ЧЧЧ

.

ЧЧ

%

7

A-3:

CALIBRATE
URV

ЧЧЧ

.

ЧЧ

%

< ENT > < CL >

ЧЧЧ

.

Ч

kPa

ЧЧЧ

.

Ч

kPa

ЧЧЧ

.

Ч

kPa

LRV

CL

CL

ENT

CL

ENT

URV

< URV >

< Zero adjustment >

< Span adjustment >

B : OUTPUT ADJ

Zero/span adjustment

Zero and span are adjustable by apply-
ing an actual pressure.
When pressing under display 1
the screen for zero adjustment 2
appears, and that for span adjustment 5
appears when pressing .
Under display 2 , after applying actual
pressure equal to zero point, press
two times. Zero adjustment will
be over.
When adjustment is made at any point
other than zero, input the pressure value
at that point at the display of 2 , then
press the key at the display of 3
while applying a corresponding pres-
sure to the transmitter.
Under display 5 , after applying actual
pressure equal to desired span, press
two times. Span adjustment
will be over.
When adjustment is made at any point
other than span, input the pressure value
at that point at the display of 5 , then
press the key at the display of 6
while applying a corresponding pres-
sure to the transmitter.

Press LRV or URV at display of 1 .
When the following is displayed, it means that calibration can not be made because
Menu No. H: LINEARIZE is effective. In this case, set INVALID on the panel of
No. H: LINEARIZE.

1. Span adjustment should be performed after zero adjustment is completed.
2. When the actual input exceeds the adjustable range, [NOT CALB ] is

displayed.
In this case, adjustment is required again.

Adjustable range

Zero adjustment: Within

±40% of maximum span

Span adjustment: Within

±20% of calibrated span

3. When the adjustment point does not meet the following condition,

[SETTING ERR] is displayed. In this case, adjustment is required again.

Adjustment point setting condition

–1.000%CS

(*)

PL 100.000%CS

(*)

0.000%CS

(*)

PH 110.000%CS

(*)

A-1:CALIBRATE
Can’t proceed.
Set Linearize
invalid

(*) : CS (Calibrated Span) is equal to measuring range.

Important

PL =

(Lower adjustment point) - LRV

URV - LRV

× 100

PH =

(Higher adjustment point) - LRV

URV - LRV

Ч 100
