2-2 C141-E185
2.1.2 Function specifications
Table 2.2 shows the function specifications of the IDD.
Table 2.2 Function specifications
Specification
Item
MAS3735NC/NP MAS3367NC/NP MAS3184NC/NP
Formatted capacity/device (*1) 73.49 GB 36.77 GB 18.37 GB
Number of disks 4 2 1
Number of heads 8 4 2
Number of cylinders (*2) 27,094 27,150 27,206
Formatted capacity/track (B) 285,696 to 360,960
Number of rotations min
-1
(rpm) 15,000 ± 0.2%
Average latency time 2.00 msec
Track to Track 0.3 ms/0.5 ms
Average 3.3 ms/3.8 ms
Seek time (*3)
(Read/Write)
Full stroke 8.0 ms/9.0 ms
Start/stop time
(*4) Start time
Stop time 30 s typ. (60 s max.)
30 s typ.
Recording mode 32/34 MEEPRML
External
dimensions
Height:
Width:
Depth: 25.4 mm
101.6 mm
146.0 mm
Weight (max) 0.80 kg
Power consumption (*5) 11.5 W 8.7 W 7.5 W
Fast 5 SCSI Cable length: 6 m max
Fast 10 SCSI Cable length: 3 m max Single-
Ended
Fast 20 SCSI
Cable length: 3 m max (*6)
Cable length: 1.5 m max (*7)
Inter-
face
LVD U160
Cable length: 25 m max (*8)
Cable length: 12 m max (*9)
Disk drive
93.11 to 118.22 MB/s Data
transfer
rate (*10)
SCSI
Synchronous
mode
320 MB/s max.
Logical data block length (*11) 512 to 528 byte (Fixed length)
SCSI command specification
SPI-4 (T10/1365D Rev.7), SAM-2 (T10/1157D Rev.20),
SPC-2 (T10/1236D Rev.20), SBC (T10/996D Rev.8c)
Data buffer 8 MB FIFO ring buffer
Acostic noise (Ready) 3.6 Bels typ. (4.1 Bels max.)
