C141-E185 5-7
Table 5.1 SCSI ID setting
NC model (CN1) NP model (CN2)
SCSI
ID
39 79 40 80 1-23-4 5-6 7-8
0 Open Open Open Open Open Open Open Open
1 Short Open Open Open Short Open Open Open
2Open Short Open Open Open Short Open Open
3 Short Short Open Open Short Short Open Open
4 Open Open Short Open Open Open Short Open
5 Short Open Short Open Short Open Short Open
6 Open Short Short Open Open Short Short Open
7 Short Short Short Open Short Short Short Open
8 Open Open Open Short Open Open Open Short
9 Short Open Open Short Short Open Open Short
10 Open Short Open Short Open Short Open Short
11 Short Short Open Short Short Short Open Short
12Open Open Short Short Open Open Short Short
13 Short Open Short Short Short Open Short Short
14 Open Short Short Short Open Short Short Short
15 (*1) Short Short Short Short Short Short Short Short
*1 Set at factory shipment.
IMPORTANT
1. To set the setting terminals on NC models to short, apply voltage ranging
between -0.3 V and 0.8 V to the setting terminals externally. To set the
setting terminals on NC models to open, apply voltage ranging between
2.0 V and 5.5 V to the setting terminals from an external source.
2. Set the SCSI ID so that there are no duplicates between SCSI devices on
the same SCSI bus.
3. The priority of SCSI bus use in ARBITRATION phase is determined by
SCSI ID as follows:
7 > 6 > 5 > 4 > 3 > 2 > 1 > 0 > 15 > 14 > 13 > 12 > 11 > 10 > 9 > 8
