FUJITSU T850 - Manual (Page 16)

System configurator and order-information guide
K PRIMERGY T850 Status 2003-09-23
Section VIII Disk Array for PCI Extension Box
Mixing DPT/Adaptec and Mylex / LSI controllers
is not supported
S26361-F2569-E64
2-channel RAID Controller U160
Mylex / LSI
AcceleRAID 352 (Leopard)
64MB SDRAM ECC Cache
BBU optional
Connector:ext. 2x VHDCI
without cable
incl. SW and description (G/USA)
64/33 PCI controller, 330mm
3.3V and 5V tolerant signaling
max. 5x per system
S26361-F2569-E10
RAID Ctrl, Battery Backup Unit
max. 1x per controller
The cables of the connection from the subsystems (SX30) to the RAID controllers,
see configurator SX30.
L
Fujitsu Siemens Computers
Enterprise Products - PRIMERGY Server 16 of 18
