8
12V Battery
Charger
Connector
• Plug the charger connector into the battery A .
• Plug the charger into a standard wall outlet B .
Note: If power flow to the wall outlet is controlled by a switch, make
sure the switch is “ON”.
• Before first-time use, charge the battery for at least 18 hours.
Never charge the battery longer than 30 hours.
• Recharge the battery for at least 14 hours after each use of your
vehicle. Do not charge the battery longer than 30 hours.
• Once the battery is charged, pull firmly on the charger connector
to disconnect it from the battery. Unplug the charger from the wall
outlet. The battery is now ready to be installed in your vehicle.
Please see the Battery Installation section on page 19 for detailed
instructions on installing your battery. If your battery is already
installed in your vehicle, simply re-connect the motor harness
connector to the battery. Lower and fasten the hood.
Children can be harmed by small parts,
sharp edges and sharp points in the
vehicle's unassembled state, or by electrical
items. Care should be taken in unpacking
and assembly of the vehicle. Children should
not handle parts, including the battery, or
help in assembly of the vehicle.
WARNING
ASSEMBLY BATTERY CHARGING E
A
B
1
Dash
Sound Box
• Loosen and remove the three screws in the top of the sound box.
Remove the sound box from the dash.
H4433pr-0920
2
• Locate the battery compartment door on the back of the sound box.
• Loosen the screw in the battery compartment door.
• Remove the battery compartment door and lift to open.
• Insert three, new "AA" (LR6) alkaline batteries, as indicated inside
the battery compartment.
Hint: Use only alkaline batteries for longer battery life.
• To replace the battery compartment door, fit the tab on the door into
the slot in the back of the sound box. Tighten the screw.
Battery
Compartment
Door
F
