4.3 Replacing the Pick Roller
fi-4120C Image Scanner Operator’s Guide
57
REPLACING CONSUMABLES
4
4.3
Replacing the Pick Roller
1. Remove any documents on the ADF paper chute.
2. Remove the ADF paper chute.
3. Open the ADF by pushing the ADF button.
CAUTION
Be careful, the ADF cover may close and pinch your finger.
ADF paper chute
ADF button
The front portion
