System configurator and order-information guide
B PRIMERGY RX600 S3 Status 2007-01-24
Section III Memory
The system can be equipped with up 4 memory boards with 2 memory banks each.
One Memory Board is allready supplied in the base unit.
Each memory board can be equipped with up to 2x 8GB = 16GB memory.
The maximal extension is 64GB with 4GB modules!
No mix of modules within one memory bank is allowed.
For each basic unit, one pair of memory modules has to be ordered with the ordercode of "Base Memory"
(either 2GB = 2x1GB, 4GB = 2x2GB or 8GB = 2x4GB)
Note**: The price of the smallest Base Memory is already included in the basic unit,
The price of the other Base Memories is the Delta to the smallest Base Memory
Additional memory extensions (Upgrade Memory) can still be configured for the standard market price.
ECC with memory scrubbing function is standard for RX600 S3.
Optional hot-spare memory functionality can be configured in the BIOS (redundant memory bank n + 1)
RX600 S3 supports the memory protection through Memory Mirroring or Memory RAID.
Memory Mirroring requires 2 or 4 Memory boards, Memory RAID requires 4 Memory boards.
see Note** above
S26361-F3072-B622 S26361-F3072-B623 S26361-F3072-B624
Base memory 2 GB Base memory 4 GB Base memory 8 GB
DDR RAM PC2-3200 ECC DDR RAM PC2-3200 ECC DDR RAM PC2-3200 ECC
with chipkill support with chipkill support with chipkill support
consisting of 2 modules consisting of 2 modules consisting of 2 modules
with 1 GB each with 2 GB each with 4 GB each
occupies one bank occupies one bank occupies one bank
1x per base system 1x per base system 1x per base system
S26361-F3072-E622 S26361-F3072-E623 S26361-F3072-E624
Upgrade memory 2 GB Upgrade memory 4 GB Upgrade memory 8 GB
DDR RAM PC2-3200 ECC DDR RAM PC2-3200 ECC DDR RAM PC2-3200 ECC
with chipkill support with chipkill support with chipkill support
consisting of 2 modules consisting of 2 modules consisting of 2 modules
with 1 GB each with 2 GB each with 4 GB each
occupies one bank occupies one bank occupies one bank
max. 1x per base system max. 1x per base system max. 1x per base system
S26361-F3125-E130
Memory Board with 2 banks
for 2 modules each
max. 3x per system
up to 3x
memory
upgrade S26361-F3072-E622 S26361-F3072-E623 S26361-F3072-E624
boards Upgrade memory 2 GB Upgrade memory 4 GB Upgrade memory 8 GB
DDR RAM PC2-3200 ECC DDR RAM PC2-3200 ECC DDR RAM PC2-3200 ECC
with chipkill support with chipkill support with chipkill support
consisting of 2 modules consisting of 2 modules consisting of 2 modules
with 1 GB each with 2 GB each with 4 GB each
occupies one bank occupies one bank occupies one bank
max. 2x per memory board max. 2x per memory board max. 2x per memory board
C
