System configurator and order-information guide
I PRIMERGY RX600 S3 Status 2007-01-24
Section X Communication / Network
on-board LAN Controller
Teaming: Failover, Load Balancing
Dual Gbit Ethernet Contr. on-board The Intel LAN Controllers Pro 1000MT, 1000MF, 1000PT, 1000PF
BroadCom BCM5704 can be used with the on-board controller in Teaming Mode
With Broadcom on-board adapters for Gigabit Ethernet must be used
ext: 2 x RJ 45 connector for the teaming the Broadcom driver.
Two onboard LAN ports can likewise educate a team.
A) Single Port LAN Adapter PCI-X
S26361-F3054-E1 S26361-F3053-E1
Gigabit Ethernet Contr. 1000SX Gigabit Ethernet Controller 1000TX
Eth. Ctrl 1x1Gbit PCI-X Pro/1000MF LC Eth Ctrl 1x1Gbit PCI-X Pro/1000MT Cu
Intel PRO/1000 MF Server Adapter Intel PRO/1000 MT Server Adapter
PCI-X (PCI64/133), min 165 mm PCI-X (PCI64/133)
ext:LC-connector ext: for RJ45-connector, Cat 5
max. 3x per system max. 3x per system
3x
B) Dual Port LAN Adapter PCI-X
S26361-F3011-E1
Gigabit Ethernet Controller Dual 1000TX
Eth Ctrl 2x1Gbit PCI-X PRO/1000MT Cu
Intel Pro/1000MT Dual Port Server Ad.
PCI-X (PCI64/133)
ext: for RJ45-plug, Cat 5
max. 1x per system
C) Single Port LAN Adapter PCIe
S26361-F3241-E1 S26361-F3242-E1
Gigabit Ethernet Contr. 1000SX Gigabit Ethernet Controller 1000TX
Eth. Ctrl 1x1Gbit PCIe Pro/1000PT Eth. Ctrl 1x1Gbit PCIe Pro/1000PF
Intel PRO/1000 MPT Server Adapter Intel PRO/1000 PF Server Adapter
PCIe x1 PCIe x4
ext:LC-connector ext: for RJ45-connector, Cat 5
max. 3x / 4x per system max. 3x / 4x per system
In SAS version
3x / 4x max. 3x PCIe controller
D) Dual Port LAN Adapter PCIe x4 can be installed
while stocks last
S26361-F3143-E1 S26361-F3228-E1
Gigabit Ethernet Contr. dual 1000TX Gigabit Ethernet Controller Dual 1000TX
Eth. Ctrl 2x1Gbit PCIe PRO/1000P Cu Eth Ctrl 2x1Gbit PCIe PRO/1000PT Cu
Intel Pro/1000P dual Server Adapter Intel Pro/1000PT dual Server Adapter
PCIe x4, 170mm PCIe x4
ext: for RJ45-plug, Cat 5 ext: for RJ45-plug, Cat 5
connection with Cat 5 cabling max. 3x / 4x per system
SW: VLAN, Fast & Gbit Etherchannel
max. 3x / 4x per system
J
Fujitsu Siemens Computers Enterprise Products PRIMERGY Server 15 of 17
