System configurator and order-information guide

Start PRIMERGY RX600 S3

PRIMERGY RX600 S3 Status 2007-01-24

Section

Basic unit

PRIMERGY RX600 S3

SCSI

PRIMERGY RX600 S3

SAS

Rack unit 4U

SCSI

basic unit with:

SAS

basic unit with:

Basic Unit including:

- 2 hot-plug power supply (redundant)

- 3 + 2 bays for 1" HDD`s (two channels)

- 8 bays for 2.5" SAS HDD`s

- 2 hot-plug fan modules (redundant)

- LCD-Display for LocalView (Service Display)

PCI Slots

- 1 bay (0,5" height) for CD- or DVD-ROM

- 1x 64bit / 133MHz PCI-X slot (hot plug)

- 1x 5.25" bays FH (1,6" high) for accessible drives

- 2x 64bit / 100MHz PCI-X slot

- Rack- mounting kit

PCIe x4 slot (hot plug)

- 1x PCIe x8 slot (hot plug)

Systemboard with

- Intel E8501 chipset with 800MHz Frontside Bus

- onboard RAID 5 functionality

- SAS RAID 5 Controller

- 1x XEON MP dua core processor

with 256MB Cache (BBU optional)

with 256MB Cache and BBU

(2nd, 3rd and 4th as option)

- 1 memory board (2nd, 3rd and 4th as option)

- Ultra 320 SCSI-controller (LSI 53C1030)

- memory of basic units selectable via

- Dual LAN-Controller 1GBit on-board

base memory order codes

WOL-capable (BroadCom 5704)

2.60GHz/4MB 7110M

S26361-K988-V410

2.60GHz/4MB 7110M

S26361-K988-V510

- VGA Controller on-board

3.00GHz/4MB 7120M

S26361-K988-V420

3.00GHz/4MB 7120M

S26361-K988-V520

(ATI Radeon 7000M, 16MB RAM)

3.20GHz/8MB 7130M

S26361-K988-V430

3.20GHz/8MB 7130M

S26361-K988-V530

- Server Management Controller on-board

3.40GHz/16MB 7140M

S26361-K988-V440

3.40GHz/16MB 7140M

S26361-K988-V540

(RSB 2 Board optional)

- ServerView Suite Software package

incl. ServerStart, ServerBooks,

Management Software and Updates

PRIMERGY PRIMECENTER- Rack

- Interfaces:

Front side

3x USB 2.0

SNP:SY-F1647E301-P

1x VGA (15 pin)

Installation ex works for one

"Rack-mounting ex factory"

server or subsystem.

This service is to be ordered once

Rear Side

Hereby the rack will be delivered

per installable server/storage

2x USB 2.0

completely pre-mounted and

subsystem, in order to get the

1x VGA (15 pin)

all wired connections are tested.

server/storage subsystem

1x RS-232-C (serial, 9 pin)

With racks 12U, 24U, 38U:

mounted into the PRIMERGY racks.

2x RJ45 (on board LAN)

Systems and components

In case of the 46 U PRIMERGY rack,

no PS/2 connection for KB / Mouse

will be delivered installed in the rack

this service has to be ordered,

(USB connectivity must be used instead)

With racks 46U:

to get the mounting kits and the

Systems and components

cables installed

will be delivered separately

To be ordered only together with

a PRIMERGY-

Rack Mounting kit is part of the basic unit PRIMERGY RX600 S2

PRIMECENTER rack

- 1 pair of telescopic rails (713 - 812mm)

e.g.:

- 1 bracket DC-PC-Rack

S26361-K826-V10x

- 1 cable management for DC-PC-racks

refer configurator DC-Rack

This kit allows for mounting of TX/RX600 S3 in in FSC 19" DataCenter- and

max. 1x per System

PRIMECENTER- racks and all server racks conforming to EIA standard EIA-310-D for 19" racks.

Therefore the mounting kit is variable in depth from 713 - 812mm
Installation in PRIMERGY 19" Classic rack is not possible.

Due to the heat dissipation of the system, sufficent cooling couldn´t be enabled in classic rack.

Connetion for KVM switch / Rack console

- RC23 can be directly connected (both USB and PS/2 connections)

- KVM S2 series needs the KVM S2 Adapter USB<->VGA

- For ES4/8+ KVM series with PS/2 connector as well as for standard PS/2 KB / Mouse

an additional USB to PS/2 adapter must be bought additionally and connected to the RX600 S3.

The adapter offers 2x PS/2 ports.

Adaper order number, to purchase via PRIMEPOWER, is:

D:GP70P-KA01 Adapter for PS/2<->USB

- Appropriate FSC USB keyboard is S26381-K340-V1*

This keyboard also needs USB cable T26139-Y3812-V1
