System configurator and order-information guide
A PRIMERGY RX600 S3 Status 2007-01-24
Section II Processor
A 4-way processor system requires a multi-processor operating system
Later upgrading to a four-way-processor system is also possible
VRM´s for 1st/2nd CPU are on the Motherboard, for the 3nd / 4th CPU addition VRM Modules are required.
Extension CPUs must have identical cache size and clock rate
2. CPU
S26361-F3124-E410 S26361-F3124-E420 S26361-F3124-E430 S26361-F3124-E440
Xeon MP 7110M 2.60GHz Xeon MP 7120M 3.00GHz Xeon MP 7130M 3.20GHz Xeon MP 7140M 3.40GHz
800 MHz FSB 800 MHz FSB 800 MHz FSB 800 MHz FSB
with 4MB TLC on Chip, with 4MB TLC on Chip, with 8MB TLC on Chip, with 16MB TLC on Chip,
heat sink and "Easy retention" heat sink and "Easy retention" heat sink and "Easy retention" heat sink and "Easy retention"
occupies socket for one CPU occupies socket for one CPU occupies socket for one CPU occupies socket for one CPU
max. 1x per system max. 1x per system max. 1x per system max. 1x per system
3./4. CPU
up to 3
upgrade
S26361-F3124-E800
CPU´s VRM module for 3rd/4th CPU
max. 1x per system
S26361-F3124-E410 S26361-F3124-E420 S26361-F3124-E430 S26361-F3124-E440
Xeon MP 7110M 2.60GHz Xeon MP 7120M 3.00GHz Xeon MP 7130M 3.20GHz Xeon MP 7140M 3.40GHz
800 MHz FSB 800 MHz FSB 800 MHz FSB 800 MHz FSB
up to with 4MB TLC on Chip, with 4MB TLC on Chip, with 8MB TLC on Chip, with 16MB TLC on Chip,
2x heat sink and "Easy retention" heat sink and "Easy retention" heat sink and "Easy retention" heat sink and "Easy retention"
occupies socket for one CPU occupies socket for one CPU occupies socket for one CPU occupies socket for one CPU
max. 2x per VRM module max. 2x per VRM module max. 2x per VRM module max. 2x per VRM module
B
