4.2. Client Side Connection Descriptions
Section Title
Connections
Column Title Function Legal Values
Port
Specify which port the device is
connected to the FieldServer
P1-P8, R1-R2 1
Protocol Specify protocol used TGM-Serial, ATMI-TGM-Serial
Baud* Specify baud rate
110 – 19200, standard baud
rates only (Vendor limitation)
Parity* Specify parity None (Vendor limitation)
Data_Bits* Specify data bits 8 (Vendor limitation)
Stop_Bits* Specify stop bits 1
Handshaking* Specify hardware handshaking
None
Poll _Delay* Time between internal polls 0-32000 seconds, 1 second
Example
//
Client Side Connections
Connections
Port,
Protocol, Baud, Parity, Handshaking, Poll_Delay
P8, TGM-Serial, 9600, None, None, 0.100s
4.3. Client Side Node Descriptors
Section Title
Nodes
Column Title Function Legal Values
Node_Name Provide name for node Up to 32 alphanumeric characters
Node_ID
This parameter is not required for
the TGM driver. However, if you
intend to use the Node_Status
function with a Data Array then
the Node_ID must be specified.
1-255
Protocol Specify protocol used TGM-Serial, ATMI-TGM-Serial
Connection
Specify which port the device is
connected to the FieldServer
P1-P8, R1-R2 1
Example
// Client Side Nodes
Nodes
Node_Name, Node_ID, Protocol, Connection
PLC 1, 1, TGM-Serial, P8
1
Not all ports shown are necessarily supported by the hardware. Consult the appropriate Instruction
manual for details of the ports available on specific hardware.
