Appendix A.2. Malfunction Table

When an event is reported in the Incident Report (QIR) then the driver compares the event
description to text in the table below. If the text matches an an entry in the ‘Malfunction’
column (and is preceeded by the string MALFUNC) then the Data Array element at the
specified offset is set to 1. If the text matches the ‘Return to Normal’ text then the
malfunction is considered as cleared and the Data Array element is set to zero.

The Data Array elements are all set to zero when
Event 19 reports ” ALARM RESET “ or Event 37 reports “ALL MALFUNCTIONS CLEAR”

The Malunction text strings generated by the TGM unit are not the same for all units. They
can be customized in theTGM’s config.dat file. For this reason, this driver allows the strings
in the table below to be customized too – see Appendix B.5. In addition to allowing this
table to be customised in the configuration file, the driver can use a config.dat file to directly
customise the table – see Appendix B.7

Offset

Malfunction

Return to Normal

20

BASELINE OUT OF RANGE

BASELINE BACK TO NORMAL

22

IGNITER SWITCH IS ON

IGNITER SWITCH IS OFF

24

FLAME IGNITION DISABLED

FLAME IGNITION ENABLED

26

LOW VACUUM

VACUUM BACK TO NORMAL

28

FLAMEOUT RESTART

FLAMEOUT BACK TO NORMAL

30

LINE LEAK TEST MALFUN

LINE LEAK BACK TO NORMAL

32

POWER FAILURE

POWER RESTORED

38

FAILED TO LOAD PROGRAM

39

DPM TIMEOUT

DPM BACK TO NORMAL

41

RELAY FILE ERROR

OPERATIONS CHECK DONE

45

CHECK I/O AND FUSES

I/O AND FUSES OK NOW

47

TGM IN DEBUG MODE

48

DISK NEARLY FULL

ADEQUATE DISK STORAGE NOW

50

FLAMEOUT CONDITION

RETURN FROM FLAMEOUT

52

FAILED FLAME TEST

FLAME TEST OK NOW

54

FAILED RESPONSE TEST

RESPONSE TEST OK NOW

56

FAILED BLOCK LEAK CHECK

BLOCK LEAK CHECK OK NOW

58

ANALOG SUBSYSTEM FAILURE

ANALOG SUBSYSTEM NORMAL

60

ANALOG CHANNEL FAILURE

ANALOG CHANNEL NORMAL

62

PRINTER OFF LINE

PRINTER BACK TO NORMAL

64

REMOTE OFF LINE

REMOTE BACK TO NORMAL

66

DISK READ/WRITE ERR

DISK BACK TO NORMAL

68

LAN READ/WRITE ERROR

LAN BACK TO NORMAL

70

DISK FULL - DATA LOST

DISK NO LONGER FULL

75

HIGH SAMPLE VARIANCE

SAMPLE VARIANCE OK NOW

80

COUS SENSOR TIMEOUT

COUS TIMEOUT CORRECTED

82

COUS GETTER INOPERATIVE

COUS GETTER OK NOW

84

ACOUSTIC SENSOR FAILURE

ACOUSTIC SENSOR RECOVERD

86

GETTER TEMPERATURE LOW

GETTER TEMPERATUR OK NOW

88

LOW SAMPLE FLOW

SAMPLE FLOW OK NOW

90

TGM HYDROGEN LEAK

HYDROGEN LEAK REPAIRED
