FS-8700-103_ATMI_TGM_Serial Manual Page 24 of 28
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com
Tel : (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: [email protected]
Message Notes and Corrective Action
∼
TGM: #21 FYI. Malfunction.
Don’t recognize <%s> But
sounds like <%s>.
The driver has found a malfunction but could not match it
exactly to a malfunction in the Malfunction Table. The
driver used a soundex function which looks for matches
based on a ‘sounds like’ evaluation. As the match is not
exact the driver provides the alert.
To suppress this message in the future, note the message
and add it to the Malfunction Table. Notes in Appendix B.5
provide information on how to do this.
TGM: #22 FYI. Return to
Normal. Don’t recognize
<%s>But sounds like <%s>.
The driver has found an event description that is being
evaluated as a potential ‘Return to Normal’ message, but
could not match it exactly to a ‘Return to Normal’ in the
Malfunction Table. The driver used a soundex function
which looks fro matches based on a ‘sounds like’
evaluation. As the match is not exact the driver provides the
alert.
To suppress this message in the future, note the message
and add it to the ‘Return to Normal' Table. Notes in
Appendix B.6 provide information on how to do this.
TGM: #23 FYI. Duplicate
Malfunction Number=<%d>.Text
has been updated from=<%s>
to=<%s>
TGM: #24 Err. No space. Reject
Malfunction=<%s> Index
Val=%d
TGM: #25 FYI. User added
Malfunction=<%s> Index
Val=%d
If these messages are produced then the driver processes
the TGM config file. Read Appendix B.7 for more
information.
TGM: #26a Err. Malfunction=%s
Index value=%d > 99.
The maximum malfunction index value is 99. Use the
procedure in Appendix B.5 to modify the malfunction index
value.
4
TGM: #27 Err. Event=%s is
Unknown. Read manual.
It is almost impossible for the driver to distinguish between
‘Return to Normal’ events and those events not associated
with a malfunction. When a non-malfunction event is found
that doesn’t match the entries in the Return to Normal Table
then this message is printed. It is printed 20 times and then
suppressed.
Ignore the messages if they clearly are not ‘Return to
Normal’ events that correspond to Malfunctions. If, however,
they are obviously associated with Malfunctions then add
the description to the ‘Return to Normal’ Table. Notes in
Appendix B.6 provide information on how to do this.
TGM: #28 Err
TGM_Function=%s invalid.
This message is printed during Map Descriptor Validation.
The function is not recognized. Correct the configuration
using information found in section 4.4.2
4
4
Modify the configuration CSV file. Download the modified file to the FieldServer and Reset the
FieldServer for the changes to take effect.
